Access point CUDY AP3000D (Wi-Fi 6)
Product reference: 26-6971690793937
  • Type: Access Point
  • Model: CUDY AP3000D 1.0
  • Wi-Fi standard: Wi-Fi 6
  • Ports:1 x 1Gbps RJ45
  • Wi-Fi speed: up to 574 Mbps @ 2.4 GHz; 2402 Mbps @ 5 GHz
  • MIMO technology: 2x2 MIMO
  • Operating distance: 220 m
  • Power consumption: ≤ 12 W
  • Power supply: 802.3af/at PoE; 12V Passive PoE; 12V 1A DC
  • Operating temperature: 0°C to 40°C
Access point CUDY AP3000D (Wi-Fi 6)

Access point CUDY AP3000D (Wi-Fi 6)

Product reference: 26-6971690793937
  • Type: Access Point
  • Model: CUDY AP3000D 1.0
  • Wi-Fi standard: Wi-Fi 6
  • Ports:1 x 1Gbps RJ45
  • Wi-Fi speed: up to 574 Mbps @ 2.4 GHz; 2402 Mbps @ 5 GHz
  • MIMO technology: 2x2 MIMO
  • Operating distance: 220 m
  • Power consumption: ≤ 12 W
  • Power supply: 802.3af/at PoE; 12V Passive PoE; 12V 1A DC
  • Operating temperature: 0°C to 40°C
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
4624 €
Product in warehouse

Guarantee
24 month

Delivery from Lithuania in
2 - 6
business days

Your message has been successfully sent!
Fill in the required fields*
  • General data
  • Model version AP3000D 1.0
  • CPU 1.3 GHz Dual-Core, ARM Cortex-A53
  • Flash/ROM 16 MB (128 Mbit) NOR
  • DDR/RAM 256MB (2Gbit) DDR3
  • 5GHz Wi-Fi speed 2402 Mbps
  • 2.4 GHz Wi-Fi speed 574 Mbps
  • 5 GHz Wi-Fi streams 2T2R (2×2 MIMO) with an Extra Stream
  • 2.4 GHz Wi-Fi streams 2T2R (2×2 MIMO)
  • Wi-Fi antennas 4× Fixed
  • Max. 5 GHz antenna gain 5.6 dBi
  • Max. 2.4 GHz antenna gain 5.1 dBi
  • FEM or PA/LNA 5 GHz: 3× Internal, 2.4 GHz: 2× Internal
  • Beamforming True
  • Operating range Max: 220 m (722 ft)
  • Wall operation Two wooden walls < 10 cm, One or two concrete walls < 10-20 cm
  • Gigabit RJ45 Ports 1
  • Notes on Ethernet Accepts PoE powering
  • LED indicators System, Internet, Ethernet, WPS, 2.4 GHz Wi-Fi, 5 GHz Wi-Fi
  • Physical buttons WPS Button, Reset Button
  • Power input DC Jack, PoE via Ethernet Port
  • Feeding methods DC, Passive PoE, 802.3af/at PoE
  • DC Specification 12V 1A
  • Passive PoE voltage 12V
  • Power adapter AP3000D/DC: Input 100-240V AC, Output 12V 1A DC; AP3000D_P Injector: Input 12-48V
  • Maximum power consumption 12W (PoE or DC)
  • Operating temperature 0°C ~ 40°C (32°F ~ 104°F)
  • Storage temperature -40°C ~ 70°C (-40°F ~ 158°F)
  • Operating humidity 10% ~ 90% non-condensing
  • Storage humidity 5% ~ 95% non-condensing
  • Certificates FCC, CE
  • Installation type Desktop, Wall-mount
  • Dimensions 183.3×109×38 mm (7.22×4.29×1.5 inches)
  • Antenna Length 175 mm (6.89 inches)
  • Product weight 309.0 g (10.9 oz.)

Weight0.401 kg
