Hikvision dome DS-2CD2786G2-IZS (white, 8 MP, 40 IR, AcuSense)
Product reference: 26-6941264088547
  • MP (MegaPixel): 8 MP
  • Lens: 2.8 mm, horizontal FOV: 108°
  • Technology: AcuSense
  • Built-in microphone: Yes
  • Night illumination: 40 m. IR
  • microSD slot: Yes, 256GB
  • Operating conditions: -30 °C to 60 °C
  • Safety level: IP67
  • Video compression: H.265+
  • WiFi: No
  • Bracket/base (optional): DS-1473ZJ-155
  • Outdoor/Indoor: Outdoor
Hikvision dome DS-2CD2786G2-IZS (white, 8 MP, 40 IR, AcuSense)

Hikvision dome DS-2CD2786G2-IZS (white, 8 MP, 40 IR, AcuSense)

Product reference: 26-6941264088547
  • MP (MegaPixel): 8 MP
  • Lens: 2.8 mm, horizontal FOV: 108°
  • Technology: AcuSense
  • Built-in microphone: Yes
  • Night illumination: 40 m. IR
  • microSD slot: Yes, 256GB
  • Operating conditions: -30 °C to 60 °C
  • Safety level: IP67
  • Video compression: H.265+
  • WiFi: No
  • Bracket/base (optional): DS-1473ZJ-155
  • Outdoor/Indoor: Outdoor
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
45969 €
Product in warehouse

Guarantee
24 month

Delivery from Lithuania in
2 - 6
business days

Your message has been successfully sent!
Fill in the required fields*
TitleDescription
Sensor1/1.8" Progressive Scan CMOS
Min. lightingColor: 0.003 Lux @ (F1.4, AGC ON), 0 Lux with IR
Shutter speed1/3 s to 1/100,000 s
ExposureYes
WDR120dB
Day/nightICR Cut
Angle controlPan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
Power-off memoryYes
FocusingCar
Lens type and angle of view2.8 to 12 mm, horizontal FOV 108° to 45°, vertical FOV 58° to 25°, diagonal FOV 127° to 52°
ExposureF1.4
InstallationΦ14
IR distanceUp to 40 m
Wavelength850 nm
Smart additional lightYes
Max resolution3840 × 2160
Main stream50Hz: 20fps (3840 × 2160, 3072 × 1728) 25fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60Hz: 20fps (3840 × 2160, 3072 × 1728) 30fps (2688 × 1728) 1520, 1920 × 1080, 1280 × 720) * When the main stream resolution is 3840 × 2160, the maximum frame rate is 20 fps for all streams.
Secondary flow50Hz: 25fps (640×480, 640×360, 320×240) 60Hz: 30fps (640×480, 640×360, 320×240)
Tertiary flow50Hz: 25fps (1280×720, 640×480, 640×360, 320×240) 60Hz: 30fps (1280×720, 640×480, 640×360, 320×240)
Image compressionMain stream: H.265+/H.265/H.264+/ H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
Video bit rate32 Kbps to 16 Mbps
H.264 typeBaseLine Profile, Main Profile, High Profile
H.265 typeMain Profile
Flow typeMain stream/sub-stream/third stream
SVCH.265 and H.264 support
ROI1 fixed region for each stream
Audio sampling rate8 kHz, 16 kHz, 32 kHz, 44.1 kHz, 48 kHz
Audio compressionG.711/G.722.1/G.726/MP2L2/PCM/MP3
Audio bit rate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8Kbps-320Kbps(MP3)
Audio typeMono sound
BroadcastingUp to 6 channels
APIONVIF (PROFILE S, PROFILE G), ISAPI, SDK
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Smooth streamingYes
User/HostUp to 32 users. 3 user levels: administrator, operator and user
ProtectionPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS 1.2
Network storageMicroSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR
CustomeriVMS-4200, Hik-Connect, Hik-Central
BrowserPlug-in required live view: IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Day/Night switchDay, Night, Auto, Schedule, Triggered by Alarm In
Image enhancementBLC, HLC, 3D DNA
Image settingsSaturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software and web browser
Alarm1 input, 1 output (max. 24 VDC, 1A, 24 VAC, 1A)
Sound1 input (line in), 3.5 mm three-connector, 1 output (line out), 3.5 mm three-connector
Internal memoryBuilt-in micro SD slot, up to 256 GB
Reboot buttonYes
Communication interface10M/100M self-adaptive Ethernet port
Main eventMotion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), Scene change detection
Additional protectionIntrusion detection, line crossing detection, region entrance detection, region exiting detection (HumanVehicle classification)
Software languages32 languages ​​English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Main functionsMirror, password protection, privacy mask, watermark, IP address filter, one-key reset, anti-flicker, three streams, heartbeat
Rebooting the softwareYes
Message transmissionUpload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture, audible warning
Storage operating conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Start and operating conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Power supply12 VDC ± 25%, two-core terminal block; PoE: 802.3af, Class 3
Voltage and current consumption12 VDC, 0.9 A, max. 10.8 W PoE: (802.3af, 36 V to 57 V), 0.4 A to 0.2 A, max. 12.9 W
Power interface2-core terminal block
MaterialMetal
Camera dimensionsΦ153.5 × 133.2 mm (Φ6″ × 5.2″)
Package dimensions244 × 174 × 173 mm (9.6" × 6.9" × 6.8")
Camera weight1080g (2.4lb.)
Weight with packaging1671 g (3.7 lb.)
ProtectionIngress protection: IP66 (IEC 60529-2013), IK10 (IEC 62262:2002)
EMCCE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
SecurityUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
Environmental protectionCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

Manufacturer codeKIP2CD2786G2-IZS
ManufacturerHikvision
Weight1.274 kg
