- In stock
Hikvision dome DS-2CD1047G2-LUF F2.8 (white, 4 MP, 30 m. LED, ColorVu)
Product reference:
26-6931847178543
- MP (MegaPixel): 4 MP
- Lens: 2.8 mm, horizontal FOV: 96°
- Technology: ColorVu
- Built-in microphone: Yes
- Night lighting: 30 m. LED
- microSD slot: Yes, 256GB
- Operating conditions: -30 °C to 60 °C
- Safety level: IP67
- Video compression: H.265+
- WiFi: No
- Bracket/base (optional): DS-1280ZJ-XS
- Outdoor/Indoor: Outdoor
Hikvision dome DS-2CD1047G2-LUF F2.8 (white, 4 MP, 30 m. LED, ColorVu)
Product reference:
26-6931847178543
- MP (MegaPixel): 4 MP
- Lens: 2.8 mm, horizontal FOV: 96°
- Technology: ColorVu
- Built-in microphone: Yes
- Night lighting: 30 m. LED
- microSD slot: Yes, 256GB
- Operating conditions: -30 °C to 60 °C
- Safety level: IP67
- Video compression: H.265+
- WiFi: No
- Bracket/base (optional): DS-1280ZJ-XS
- Outdoor/Indoor: Outdoor
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Lithuania in
2 - 6
business days
- Camera
- Sensor 1/3" Progressive Scan CMOS
- Max resolution 2560 × 1440
- Min. lighting Color: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with light
- Shutter speed 1/3 s to 1/100,000 s
- Day Night 24/7 color imaging
- Changing the angle Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
- Lens
- Lens type Fixed focal lens, 2.8 and 4 mm optional
- Focal Length FOV
2.8 mm, horizontal FOV: 96°, vertical FOV: 52°, diagonal FOV: 113°
4 mm, horizontal FOV: 75°, vertical FOV: 40°, diagonal FOV: 89°
- Lens installation M12
- Iris type Fixed
- Aperture F1.0
- Depth of field
2.8 mm: 2 m to ∞
4 mm: 2.7 m to ∞
- DOROUS
- DOROUS
2.8 mm, D: 64 m, O: 25 m, R: 12 m, I: 6 m
4 mm, D: 82 m, O: 32 m, R: 16 m, I: 8 m
- Lighting
- Additional lighting type White Light
- Additional lighting range Up to 30 m
- Smart additional lighting Yes
- Image
- Main stream
50Hz:
20fps (2560×1440)
25 fps (1920×1080, 1280×720)
60Hz:
20fps (2560×1440)
24 fps (1920×1080, 1280×720)
- Secondary flow
50Hz: 25fps (1280×720, 640×480, 640×360)
60Hz: 24fps (1280×720, 640×480, 640×360)
- Image compression
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG
- Video bit rate 32 Kbps to 8 Mbps
- H.264 type Baseline Profile, Main Profile, High Profile
- H.265 type Main Profile
- Bit rate control CBR,VBR
- Region of Interest (ROI) 1 fixed region(s) for main stream
- Sound
- Audio type -U: Mono sound
- Removing extraneous sounds -U: Yes
- Audio sampling frequency -U: 8kHz/16kHz
- Audio compression -U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
- Audio bit rate -U: 64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
- Internet
- Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
- Live video viewing Up to 6 channels
- API Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)), ISAPI, SDK
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- Security Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
- Customer iVMS-4200,Hik-Connect
- Browser
Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Firefox 52.0+
- Photo
- Wide Dynamic Range (WDR) 120 dB
- SNR ≥ 52 dB
- Day/Night mode Day, Night, Auto, Schedule
- Photo beautification BLC,HLC,3D DNA
- Photo settings Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
- Privacy mask 4 programmable polygon privacy masks
- Interface
- Web interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
- Internal memory
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
- Built-in microphone -U: Yes
- Reboot button -F: Yes
- Features
- Main functions Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception
- Interface Upload to FTP/memory card (-F), notify surveillance center, send email, trigger recording (-F), trigger capture
- Home
- System parameters
12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug,
PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W
- Material Aluminum alloy body
- Size
Ø76.6 mm × 164.4 mm (Ø3 × 6.5\")"
- Package size 234 mm × 120 mm × 117 mm (9.2" × 4.7" × 4.6")
-
- L: Approx. 410 g (0.9 lb.); -LUF: Approx. 430 g (0.9 lb.)
- Weight with packaging
- L: Approx. 630 g (1.4 lb.); -LUF: Approx. 650 g (1.4 lb.)
- Storage conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Working conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Language English, Ukrainian
- Main functions Heartbeat, anti-banding, mirror, password protection, password reset via email
- Approvals
- EMC
FCC: 47 CFR Part 15, Subpart B,
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
RCM: AS/NZS CISPR 32: 2015,
KC: KN32: 2015, KN35: 2015
- Security
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
- Environmental protection
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
- Protection IP67: IEC 60529-2013
| Manufacturer code | KIPDS2CD1047G2LUF |
| Manufacturer | Hikvision |
| Weight | 0.44 kg |
