The PoE Switch is an unmanaged switch equipped with a high-performance switching engine and large cache, ensuring smooth transmission of video streams. It features four DIP switches and supports PoE Watchdog, long-distance PoE, VIP port, and port isolation functions. The red port supports IEEE 802.3bt and Hi-PoE standards and can deliver up to 90 W. The device operates reliably within a temperature range of −10 °C to 55 °C and provides EMC compliance along with protection against overvoltage, overcurrent, static electricity, lightning strikes, pulses, and other types of interference.
BT 90W (Red Port)
The red ports support IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, and Hi-PoE standards with a maximum output power of up to 90 W per port, making them suitable for powering high-consumption devices.
Long Distance PoE
Each PoE port supports transmission distances of up to 250 m, meeting long-range wired transmission requirements, with bandwidth adjusted to 10 Mbps for extended reach.
PoE Watchdog
This innovative feature automatically detects port status and restarts failed ports when a connection exception occurs, enabling intelligent operation and maintenance while significantly reducing manual servicing costs.
Port Isolation
Devices connected to different ports are prevented from communicating with each other without the need for VLAN configuration. This protects data from leakage through PoE ports and isolates broadcast storms, ensuring a safer and more stable network environment.
Application Scenarios
Suitable for deployment in houses, factories, offices, and similar environments.
| AC įėjimo dažnis | 50/60 Hz |
| AC įėjimo įtampa | 100 - 240 V |
| Adreso lentelės dydis | 8000 įrašai |
| Aukštis | 44 mm |
| Bendrosios galios per Eternetą (PoE) charakteriskos | 360 W |
| Bruto svoris | 3.5 kg |
| Darbo santykinės drėgmės diapazonas | 10 - 90 % |
| Darbo temperatūros diapazonas (TT) | -10 - 55 °C |
| Eterneto LAN duomenų perdavimo norma | 10,100,1000 Mbit/ai |
| Galios suvartojimas (maks.) | 400 W |
| Ilgis | 220 mm |
| Jumbo Frames palaikymas | Taip |
| Korpuso medžiaga | Plienas |
| Maitinimas per Eternetą (PoE) | Taip |
| Maitinimo per Eternetą (PoE) prievadų skaičius | 24 |
| Maitinimo šaltinis | AC |
| Model name | S3228-24GT-375 |
| Optinių perjungimo blokų tipas | Gigabitinis eternetas |
| Pagrindinių perjungimo RJ-45 eterneto prievadų skaičius | 26 |
| Pagrindinių perjungimo RJ-45 eterneto prievadų tipas | Gigabit Ethernet (10/100/1000) |
| Paketo buferio atmintis | 4 MB |
| Paketo svoris | 3260 g |
| Pakuotės aukštis | 90 mm |
| Pakuotės gylis | 342 mm |
| Pakuotės plotis | 540 mm |
| Perjungimo pajėgumas | 52 Gbit/s |
| Perjungimo sluoksnis | L2 |
| Perjungimo tipas | Ne-valdomas |
| Persiuntimo dažnis | 41.66 Mpps |
| Plotis | 440 mm |
| Pridėtas maitinimo šaltinis | Taip |
| Produkto spalva | Juoda |
| Sandėliavimo santykinis drėgmės diapazonas | 5 - 95 % |
| Sandėliavimo temperatūros norma (T-T) | -40 - 75 °C |
| Shipping Box Depth | 54 cm |
| Shipping Box Height | 34.5 cm |
| Shipping Box Weight | 3.5 kg |
| Shipping Box Width | 10 cm |
| Stovo montavimas | Taip |
| Summary | Dahua Technology PoE S3228-24GT-375. Switch type: Unmanaged, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 26. Switching optical modules type: Gigabit Ethernet. Installed SFP modules quantity: 2. MAC address table: 8000 entries, Switching capacity: 52 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE.... Power over Ethernet (PoE). Rack mounting |
| Svoris | 2660 g |
| Tinklo standartai | IEEE 802.3/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3bt/IEEE 802.3u/IEEE 802.3x/IEEE 802.3z |
| Unit Box Height | 0.345 |
| Unit Box Length | 0.54 |
| Unit Box Width | 0.1 |
| Unit Brutto Volume | 0.01863 cubm |
| Vendor Homepage | https://transmission.dahuasecurity.com/en/product-list/Business/Switches/PoESwitchForSecurity/S3228-24GT-375 |
| Vieneto aukštis | 34.5 cm |
| Vieneto gylis | 54 cm |
| Vieneto plotis | 10 cm |
| Vienetų skaičius vienoje siuntimo dėžėje | 1 |
| Įdiegtų SFP modulių kiekis | 2 |
| Įvesties srovė | 7 A |
| "Jumbo" kadrai | 15 |
