„Grandstream Networks GWN7630“ belaidis prieigos taškas

Grandstream Networks GWN7630. 2.4 GHz, 5 GHz, Maximum data transfer rate: 2330 Mbit/s. Security algorithms: WEP, WPA, WPA-PSK, WPA2, WPA2-PSK. Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 16.5 W

The GWN7630 is a high-performance 802.11ac Wave-2 Wi-Fi access point for small to medium sized businesses, multiple floor offices, commercial locations and branch offices. It offers dual-band 4×4:4 MU-MIMO technology and a sophisticated antenna design for maximum network throughput and expanded Wi-Fi coverage range. To ensure easy installation and management, the GWN7630 uses a controller-less distributed network management design in which the controller is embedded within the product's web user interface. The GWN7630 is also supported by GWN.Cloud, Grandstream's free cloud Wi-Fi management platform. It is the ideal Wi-Fi AP for voice-over-Wi-Fi deployments and offers a seamless connection with Grandstream's Wi-Fi-capable IP phones. With support for advanced QoS, low-latency real-time applications, mesh networks, captive portals, 200+ concurrent clients per AP and dual Gigabit network ports with PoE/PoE+, the GWN7630 is an ideal Wi-Fi access point for medium wireless network deployments with medium-to-high user density.

Features

Feature: 2.4 GHz
Feature: 5 GHz
Maximum data transfer rate: 2330 Mbit/s
Ethernet LAN data rates: 10,100,1000 Mbit/s
Frequency band: 2.412 - 2.484; 5.18 - 5.825 GHz
Number of users: 200 user(s)
Channel bandwidth: 80 MHz
Feature: MIMO
MIMO type: Multi User MIMO
Feature: Wi-Fi Multimedia (WMM)/(WME)
Feature: VLAN support
Feature: Quality of Service (QoS) support
Maximum outdoor range: 175 m
Transmitting power: 27 dBmW

Security

Security algorithms: WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported: 15

Protocols

Supported network protocols: IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM

Ports & interfaces

Ethernet LAN (RJ-45) ports: 2

Power

Feature: Power over Ethernet (PoE)
Power consumption (max): 16.5 W

Design

Placement: Ceiling, Wall
Product colour: White
Feature: Cable lock slot
Cable lock slot type: Kensington
Feature: Reset button
LED indicators: Status

Antenna

Antenna type: Internal
Antennas quantity: 4
Antenna gain level (max): 5 dBi

Certificates

Certification: FCC, CE, RCM, IC

Weight & dimensions

Width: 205.3 mm
Depth: 205.3 mm
Height: 45.9 mm
Weight: 590 g

Packaging data

Package width: 258 mm
Package depth: 247 mm
Package height: 86 mm
Package weight: 930 g

Packaging content

Quantity per pack: 1 pc(s)
Feature: Mounting kit
Feature: Quick start guide

Operational conditions

Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -10 - 60 °C

Logistics data

Harmonized System (HS) code: 85176990
