„Axis 01681-001“ apsaugos kamera

Axis 01681-001. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: Black, White, Form factor: Dome. Minimum illumination: 0.02 lx, Lens viewing angle, horizontal: 58.7°, Lens viewing angle, vertical: 35.7°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Optical zoom: 32x, Digital zoom: 12x, Focal length range: 4.3 - 137.6 mm

AXIS P5655-E PTZ Network Camera is a cost-effective, high performance PTZ with HDTV 1080p and 32x optical zoom. It features Forensic WDR for clarity even when there's both dark and light areas in the scene. And, Lightfinder 2.0 to capture low-light images with more saturated colors and sharper images of moving objects. It offers electronic image stabilization and enhanced security features including signed firmware and secure boot. With IP66, NEMA 4X and IK10 ratings it's resistant to both harsh weather conditions and impacts. Plus, you get two-way audio, I/O ports and extended capabilities for advanced analytics.

Performance

Type: IP security camera
Placement supported: Indoor & outdoor
Connectivity technology: Wired
Feature: PTZ control
Feature: Preset points
Feature: Wide Dynamic Range (WDR)
Feature: Day/night mode
Feature: Infrared (IR) cut-off filter
Feature: Alarm input/output

Design

Form factor: Dome
Mounting type: Ceiling/wall
Product colour: Black, White
Housing material: Aluminium
Protection features: Shock resistant
International Protection (IP) code: IP66
IK code: IK10
Feature: Weatherproof
Feature: Fog proof

Camera

Feature: Camera pan control
Feature: Camera tilt control
Minimum illumination: 0.02 lx
Lens viewing angle, horizontal: 58.7°
Lens viewing angle, vertical: 35.7°
Tilt angle range: 0 - 180°
Tilt speed: 350 °/sec
Pan range: 0 - 360°
Pan speed: 350 °/sec
Camera shutter speed: 1/66500 - 2 s

Image sensor

Number of sensors: 1
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Feature: Progressive scan
Sensor type: CMOS

Lens system

Feature: Zoom capability
Optical zoom: 32x
Digital zoom: 12x
Number of lenses: 1
Focal length range: 4.3 - 137.6 mm
Feature: Auto focus
Maximum aperture number: 4
Minimum aperture number: 1.4

Video

Maximum resolution: 1920 x 1080 pixels
Video formats supported: AVC, H.264, H.265, HEVC, M-JPEG, MPEG4
Supported graphics resolutions: 320 x 180, 1920 x 1080 (HD 1080)
Supported video modes: 1080p
Frame rate: 60 fps
Feature: Video streaming
Image quality adjustment: Brightness, Contrast, Saturation, Sharpness
Feature: Privacy masking
Feature: Text caption overlay
Feature: Image stabilizer
Bit rate control: Variable Bit Rate (VBR)

Audio

Audio system: 2-way
Audio formats supported: ADPCM, LC-AAC, LPCM, PCM
Sample rate: 48 kHz
Feature: Audio detection

Network

Feature: Ethernet LAN
Ethernet interface type: Fast Ethernet
Networking standards: IEEE 802.1x, IEEE 802.3at
Streaming method: Multicast

Storage

Feature: Card reader integrated
Compatible memory cards: SD, SDHC, SDXC
Flash memory: 512 MB
Internal memory: 1024 MB

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1
Feature: Microphone in
Feature: DC-in jack

Security

Feature: Password protection
Feature: Video motion detection
Feature: IP address filtering
Feature: HTTPS encryption

Power

Power source type: DC, PoE
Power consumption (typical): 10.5 W
Power consumption (max): 19 W

Operational conditions

Operating temperature (T-T): -30 - 55 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 100%

Weight & dimensions

Width: 188 mm
Depth: 188 mm
Height: 217 mm
Weight: 2.5 kg

Packaging content

Number of cameras: 1
Feature: Mounting kit
Feature: Manual

Logistics data

Harmonized System (HS) code: 85258900
