„GIGABYTE Z790 EAGLE AX“ pagrindinė plokštė – palaiko „Intel Core 14“ kartos procesorius, 12+1+１ fazių skaitmeninę VRM,
Prekės kodas:
6-Z790 EAGLE AX
„GIGABYTE Z790 EAGLE AX“ pagrindinė plokštė – palaiko „Intel Core 14“ kartos procesorius, 12+1+１ fazių skaitmeninę VRM, iki 7600MHz DDR5 (OC), 3xPCIe 4.0 M.2, „Wi-Fi 6E“, 2.5GbE LAN, USB 3.2 Gen 2
„GIGABYTE Z790 EAGLE AX“ pagrindinė plokštė – palaiko „Intel Core 14“ kartos procesorius, 12+1+１ fazių skaitmeninę VRM,
Prekės kodas:
6-Z790 EAGLE AX
„GIGABYTE Z790 EAGLE AX“ pagrindinė plokštė – palaiko „Intel Core 14“ kartos procesorius, 12+1+１ fazių skaitmeninę VRM, iki 7600MHz DDR5 (OC), 3xPCIe 4.0 M.2, „Wi-Fi 6E“, 2.5GbE LAN, USB 3.2 Gen 2
Jūsų palyginimo sąraše yra 3 prekės, prašome vieną pašalinti ir bandyti dar kartą.
- Įtraukti į patikusias prekes
- Pridėta į patikusias prekes
- Pašalinta iš patikusų prekių
Garantija
36 mėn.
Pristatymas iš Europos
per 6 - 11*
d. d.
| Warranty period | 3 year(s) |
| Maximum internal memory supported by processor | 192 GB |
| Supported processor sockets | LGA 1700 |
| Maximum number of SMP processors | 1 |
| Compatible processor series | Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3 |
| Processor manufacturer | Intel |
| Processor socket | LGA 1700 |
| On-board graphics card | No |
| Maximum resolution | 4096 x 2304 pixels |
| Parallel processing technology support | Not supported |
| HDCP | Yes |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Audio chip | Realtek ALC897 |
| Motherboard chipset family | Intel |
| Product colour | Bronze |
| Audio output channels | 7.1 channels |
| Motherboard chipset | Intel Z790 Express |
| Power source type | ATX |
| Motherboard form factor | ATX |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Memory slots type | DIMM |
| Supported memory types | DDR5-SDRAM |
| Number of memory slots | 4 |
| Memory channels | Dual-channel |
| Supported memory clock speed (max) | 7600 MHz |
| ECC сompatibility | ECC & Non-ECC |
| Supported memory module capacities | 12GB, 32GB, 8GB, 16GB, 48GB, 2GB, 4GB, 1GB |
| Supported memory clock speeds | 6800, 6000, 5200, 6600, 5600, 7200, 5800, 5400, 6200, 7000, 6400, 7600, 7400, 4400, 4800 |
| Maximum internal memory | 192 GB |
| Unbuffered memory | Yes |
| Depth | 244 mm |
| Width | 305 mm |
| Height | 35 mm |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Wi-Fi standards | Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), 802.11g, 802.11b, Wi-Fi 5 (802.11ac) |
| Bluetooth version | 5.3 |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| 12V power connector | Yes |
| Front panel connector | Yes |
| Total number of SATA connectors | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
| Number of EATX power connectors | 2 |
| RGB LED pin header | Yes |
| CPU fan connector | Yes |
| TPM connector | Yes |
| EPS power connector (8-pin) | Yes |
| Thunderbolt headers | 2 |
| Front panel audio connector | Yes |
| USB 2.0 connectors | 2 |
| ATX Power connector (24-pin) | Yes |
| Number of SATA III connectors | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| Clear CMOS button | Yes |
| BIOS type | UEFI AMI |
| Desktop Management Interface (DMI) version | 2.7 |
| Clear CMOS jumper | Yes |
| Bundled software | Norton® Internet Security (OEM version) LAN bandwidth management software |
| Cables included | SATA |
| Antenna included | Yes |
| Batteries included | Yes |
| RAID levels | 1, 10, 5 |
| Number of storage drives supported | 7 |
| Number of HDDs supported | 4 |
| Supported storage drive types | HDD & SSD |
| RAID support | Yes |
| Supported storage drive interfaces | M.2, SATA III |
| Headphone outputs | 1 |
| USB connector type | USB Type-A, USB Type-C |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| PS/2 ports quantity | 1 |
| HDMI version | 2.1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| WiFi-AP antenna jack | 2 |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Microphone in | Yes |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2 |
| S/PDIF out port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 2 |
| Number of M.2 (M) slots | 3 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| PCI Express x1 (Gen 3.x) slots | 2 |
| PCI Express x16 (Gen 3.x) slots | 1 |
| Battery type | CR2032 |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Battery weight | 3 g |
| Number of battery cells | 1 |
| Lithium weight per battery | 0.07 g |
| Products per shipping (inner) case | 1 pc(s) |
| Country of origin | China |
| Warnings | Avoid direct contact with electronics to prevent electrostatic damage., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal., Before starting any maintenance or installation, disconnect the product from the power supply. |
