ASUS BE19000 Quad-band WiFi 7 (802.11be) Gaming Router ROG Rapture GT-BE19000

The ROG Rapture series keeps pushing the boundaries of what is possible for gaming and networking. The new ROG Rapture GT-BE19000 is a tri-band 12-stream WiFi 7 gaming router tailored for next-gen gaming and computing. With speeds of up to 1.9 Gbps, powerful 31G wired capacity and the exclusive ROG Gaming Network, it offers new ways of accelerating your gameplay.

Model Name:GT-BE19000

Network Standard:WiFi 6 (802.11ax) WiFi 7 (802.11be) IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac IPv4 IPv6

Product Segment:BE19000 ultimate BE performance: 1376+5764+11529 Mbps

WiFi Data Rate:2.4GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40MHz, up to 1376Mbps 5GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbps 6GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160/320MHz, up to 11529Mbps

Antennas:External antenna x 8

Transmit / Receive:2.4GHz 4x4 5GHz 4x4 6GHz 4x4

Processor:2.6GHz quad-core processor

Memory:256 MB Flash and 2 GB RAM

Boosts Speed:OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 4096-QAM high data rate 20/40/80/160/320 MHz bandwidth

Operating Frequency:2.4 GHz / 5 GHz / 6 GHz 2.4 GHz 5 GHz 6 GHz

Operating Mode:Router(AiMesh router), AiMesh node, Access point, Repeater, Media bridge

I/O Ports:1 x 10Gbps for WAN/LAN 1 x 2.5Gbps for WAN/LAN 1 x 10Gbps for LAN 3 x 2.5Gbps for LAN 1 x RJ45 10/100/1000Mbps for LAN 1 x USB 3.2 Gen1 1 x USB 2.0

Buttons:WPS Button, Reset Button, Power Switch, LED control Button

LED Indicators:WAN(Internet) x1 10G LAN x1 1G/2.5G LAN x1 WPS x1 6GHz x1 5GHz x1 2.4GHz x1 Power x1

Power Supply:AC Input: 110V~240V(50~60Hz) DC Output: 12 V with max. 5 A current

Product Weight (g):2000 grams

Product Dimensions:350.41 x 350.41 x 220.6 mm

AiMesh:AiMesh • Primary AiMesh Router • AiMesh Node

Game:Game Boost / Acceleration Game Radar WTFast Mobile Game Mode Gear Accelerator ROG_First OpenNAT (Game Profile) Gaming Port Gaming Network

Parental Control:'Allow you to block access to unwanted websites and apps.' Web Apps Filters Time Scheduling Reward Parental Control Customized Internet Schedule: • Maximum Parental Control profile : 64 • Maximum Parental Control content filter rule : 64

Guest Network:'The Guest Network provides Internet connection for guests but restricts access to your local network.' 'You can create additional networks for different purposes, these networks are separate from the main network domain, to provide enhanced security, and create a comprehensive network environment with customized settings.' Support Guest Network Pro (Maximum Guest Network Rule : 2.4 GHz + 5 GHz : 5) Guest Network Connection time limit Guest Network Encryption : Open system, WPA/WPA2/WPA3 Personal

Security:AiProtection VPN WiFi Encryption: WPA/WPA2/WPA3 Personal WPA/WPA2/WPA3 Enterprise Open System OWE WPS Let's Encrypt DNS-over-TLS SSH Security Scan Firewall: • Maximum Firewall Keyword Filter : 64 • Maximum Firewall Network Service Filter : 32 • Maximum Firewall URL Filter : 64

AiProtection:AiProtection Pro • Router Security Assessment • Malicious Site Blocking • Two-Way IPS • Infected Device Prevention and Blocking

VPNs:Instant Guard VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion

Traffic Control:Adaptive QoS: • Bandwidth Monitor • Bandwidth Limiter (Maximum Bandwidth Limiter Rule : 32) Traditional QoS Traffic Monitor: • Real-time Traffic Monitor • Wired Traffic Monitor • Wireless Traffic Monitor Traffic Analyzer • Traffic Analysis Period : Daily, Weekly, Monthly • Website History

WAN:Internet Connection Type : Automatic IP, Static IP, PPPoE, PPTP, L2TP Internet Connection Type : Internet Connection Type : Internet Connection Type : • PPPoE Internet Connection Type : • PPTP Internet Connection Type : • L2TP Internet Connection Type : • Automatic IP Internet Connection Type : • Static IP Internet Connection Type : • IPSec Dual WAN 3G/4G LTE Dongle 4G/5G Auto Mobile Tethering Port Forwarding (Maximum Port Forwarding Rule : 64) 32) DMZ DDNS NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough, PPPoE relay

LAN:DHCP Server IPTV LAN Link Aggregation Manually Assign IP Address (Maximum Manually Assign IP Address Rule : 128) Wake on LAN (WOL) VLAN

Wireless:MU-MIMO UTF-8 SSID WiFi MAC Address Filter (Maximum MAC Filters : 64) Wireless Scheduler Wi-Fi Radar Airtime Fairness RADIUS Client Universal Beamforming Explicit Beamforming

USB application:4G / 5G Auto Mobile Tethering File System : HFS+, NTFS, vFAT, ext2, ext3, ext4 Safely Remove Disk AiCloud Download Master AiDisk Media Server Time Machine Samba Server FTP Server Shared Folder Privileges

User Interface:WEB: ASUSWRT APP: ASUS Router APP Operating system: ASUSWRT

Administration:Configuration Backup and Restore Diagnosis Tools Feedback System System Log New Device Connect Notification Login Captcha Connection Diagnosis Auto Firmware Update

Package Contents:GT-BE19000 tri-band gaming router RJ-45 cable Power adapter Quick Start Guide
