Wireless access point, 3000 Mbps, 2.4GHz / 5GHz Wi-Fi + 1000 Mbps Ethernet, (802.11AX), IP67.

Wireless access point, 3000 Mbps, 2.4GHz/5GHz Wi-Fi + 1000 Mbps Ethernet, (802.11AX), IP67.

Features:

• High-power industrial wireless access point with the next-generation 802.11AX Wi-Fi 6 standard.


• 3000 Mbps Wi-Fi speed via 2.4/ 5G, 1000 Mbps Ethernet.


• Adapted for outdoor conditions, protection class IP67 (protection against dust and water).


• Allows up to 128 end users to connect.


• The combination of 4 antennas supports an omnidirectional coverage area of ​​80 meters.


• Power supply via PoE.


• LED indicator system: 5G; 2.4G; WAN; LAN; SYS. Reboot button.


• It features good transmission quality, smooth roaming, low latency, automatic frequency tuning, and surge protection.


• Mounting on a pole or wall.


• This AP device can be widely used in urban gardens, observation parks, outdoor sports fields, school playgrounds, commercial spaces or farms.

Technical data:

• CPU: IPQ5018 +QCN6122/ QCN6102.


• DDR: 512MB.


• Flash: SPI NOR 8MB (1.8V) + NAND 128MB.


• Transmission power: 2.4G 20-26dBm; 5.8G 19-24dBm.


• Maximum data transfer speed: 2976Mb/s.


• Transmission speed: 574Mbps (2.4GHz). + 2402Mbps (5.8GHz).


• Wireless standard 2.4G Wi-Fi: IEEE802.11b, IEEE802.11g, IEEE802.11n, IEEE802.11ax.


• Wireless standard 5.8G Wi-Fi: IEEE802.11a, IEEE802.11n, IEEE802.11ac, IEEE802.11ax.


• LAN port: RJ45, 10/100/1000 Mbps.


• WAN port: RJ45, 10/100/1000 Mbps.


• Operating environment: -20 ~+55°C, 5~95%RH (non-condensing).


• Power supply: PoE: 48V (IEEE802.3AF)


• Power consumption: <24W.


• Antennas: built-in 4x (2x 3dBi@2.4GHz + 2x 5dBi@5.8GHz).


• Safety class: IP67 (waterproof).

Package:

• Wi-Fi access point.


• PoE power adapter.


• Network cable.


• Fastening rings.
