Digital multimeter JIMI Home JM-G3401
JIMI Home JM-G3401 is a digital multimeter for measuring voltage, current, resistance, capacitance and frequency. It features an LCD display, automatic measurement range selection, non-contact voltage detection and self-regulating fuses.
- Multifunctional digital multimeter for measuring voltage, resistance, capacitance and frequency.
- True RMS measurement technology ensures accurate readings in a variety of conditions, with automatic range selection.
- The convenient design includes a magnetic back, kickstand, and backlit display for easy use in low-light areas.
- Non-contact voltage detection (NCV) and self-regulating fuses are included for increased safety and reliability.
Features | |
|---|---|
| Product type | Digital multimeter |
| Brand | JIMI Home |
| Model | JM-G3401 |
Specifications | |
| DC voltage measurement range | 600mV/6V/60V/600V/1000V (±0.5%+3, 0.8%+10) |
| AC voltage measurement range | 500mV/6V/60V/600V/750V (±0.8%+3, 1.2%+10) |
| DC current measurement range | 60mA/400mA/6A/10A (±1.2%+10, 2.0%+10) |
| AC current measurement range | 60mA/400mA/6A/10A (±1.2%+10, 2.0%+10) |
| Resistance measurement range | 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ (±0.8%+5, 0.8%+3, 2.5%+3) |
| Capacity measurement range | 60nF/600nF/6µF/60µF/600µF/6mF/60mF (±5.5%+20, 5.0%+3) |
| Frequency measurement range | 10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz |
| Temperature range | 0°C ~ 40°C |
| Screen | LCD |
| Correct RMS value | Yes |
| Self-regulating fuse | Yes |
| Automatic shutdown | Yes, in 15 minutes |
| Power supply | 2x 1.5V AAA batteries |
| Weight | 340g (with batteries) |
| Dimensions | 153 x 70 x 53 mm |
