AV Matrix - LINDY 8x8 HDMI 4K60 Matrix 18Gbps HDCP 2.2 Audio Transmission
Product reference:
14-4002888383349
Connect eight 4K UHD sources to eight 4K UHD displays supporting HDMI 2.0b and a maximum resolution of 3840x2160@60Hz. The device offers 18Gbps bandwidth, HDCP 2.2 support, and a variety of audio options, including HDMI audio pass-through up to 7.1CH.
AV Matrix - LINDY 8x8 HDMI 4K60 Matrix 18Gbps HDCP 2.2 Audio Transmission
Product reference:
14-4002888383349
Connect eight 4K UHD sources to eight 4K UHD displays supporting HDMI 2.0b and a maximum resolution of 3840x2160@60Hz. The device offers 18Gbps bandwidth, HDCP 2.2 support, and a variety of audio options, including HDMI audio pass-through up to 7.1CH.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
LINDY 8x8 HDMI 4K60 Matrix 18Gbps HDCP 2.2 Audio Transmission
Connect eight 4K UHD sources to eight 4K UHD displays with HDMI 2.0b support and a maximum resolution of 3840x2160@60Hz. Features include 18Gbps bandwidth, HDCP 2.2 support, and a variety of audio options, including HDMI audio pass-through up to 7.1CH.
- Supports 8 HDMI inputs and outputs with 4K resolution at 60Hz for high-quality images.
- Offers advanced audio support, including HDMI audio pass-through up to 7.1CH and Dolby Atmos.
- Multiple control options: buttons, IR remote control, RS-232 and IP control.
- Includes special features such as ARC, HDR 10, and 4K to 1080p output downscaling.
Features | |
|---|---|
| Product type | AV Matrix Switcher |
| Model | 8x8 HDMI 4K60 Matrix |
Specifications | |
| AV interface | HDMI® 2.0b |
| Supported bandwidth | 18Gbps |
| Maximum resolution | 3840x2160@60Hz RGB 8bit |
| HDCP support | 2.2 |
| Supported audio type |
|
| IR support | 38kHz |
| CEC support | Yes |
| Serial interface | RS-232 |
| LED/LCD display | OLED |
| Management options | Buttons, IR, RS-232, IP |
| Special features | ARC, 4K to 1080p Output Downscaling, Dolby Vision, Dolby Atmos, HDR 10 |
Connectors | |
| Input connectors | 8 x HDMI® (Female) |
| Output connectors | 8 x HDMI® (Female), 8 x 3.5mm (Female), 8 x Coaxial (Female) |
| Control connections | RS-232 (Female), RJ45 (Female) |
| Power connector | 5.5/2.5mm |
Physical properties | |
| Dimensions | 440x200x45mm (17.32x7.87x1.77in) |
| Housing material | Metal |
| Net weight | 2.83kg (6.24lb) |
| Working temperature | -10°C - 45°C (14°F -113°F) |
| Storage temperature | -20°C - 60°C (-4°F - 140°F) |
| Humidity | 20 - 90% (non-condensing) |
| Power requirements | 12VDC 5A |
| MTBF | 50,000 hours |
| Color | Black |
