All-in-one router and security gateway with an integrated PoE switch and network video recorder


The Dream Machine Special Edition (UDM SE) is an enterprise-grade UniFi OS Console capable of helping home and business owners alike seamlessly scale and manage their networks with high-speed, dual-WAN connectivity (10G SFP+ and 2.5GbE RJ45 ports), a Gigabit, PoE switch, and a network video recorder (NVR) with 128 GB of internal storage. Powered by UniFi OS, the UDM SE gives you full control of all your UniFi devices, including access points, Protect cameras, Talk phones, and Access readers. It's also a future-proof console since it will be able to run all upcoming UniFi OS applications. Engineered for end-to-end simplicity, the UDM SE features an integrated Bluetooth radio that streamlines the initial setup and configuration process, which can be completed in minutes with the UniFI Network application (web or mobile).



  • 1.7 GHz quad-core processor

  • Dual WAN ports (10G SFP+ and 2.5GbE RJ45)

  • (8) GbE RJ45 ports, including (6) 802.3af PoE and (2) 802.3at PoE+ LAN ports

  • (1) 10G SFP+ LAN port

  • (1) 1.3' LCM color touchscreen for at-a-glance network monitoring

  • Customizable internet threat filtration and traffic identification for enhanced network security

  • Quick, Bluetooth-powered setup via the UniFi Network web application or mobile app

  • 1U-sized, rack-mountable device

  • Connect a SmartPower Redundant Power System to create an uninterruptible network

  • Integrated security gateway and UniFi Protect-ready NVR that supports compatible 3.5' HDDs

  • 128 GB integrated storage for full UniFi OS Application experience






































































































































Mechanical
Dimensions

442.4 x 43.7 x 285.6 mm (17.42 x 1.72 x 11.24')


Weight

4.95 kg (10.91 lb)


Enclosure materials

Aluminium CNC, SGCC steel


Mount material

SGCC steel rack mount


Hardware
Processor

Quad-Core ARM®Cortex®-A57 at 1.7 GHz


System memory

4 GB DDR4


On-board storage

16 GB eMMC

Integrated 128 GB SSD


IDS/IPS throughput

3.5 Gbps*


*Measured with iPerf3


Max. power consumption (excluding PoE output)

50W


Power method

(1) Universal AC input, 100-240VAC, 4.4A Max, 50/60 Hz


(1) USP-RPS DC input, 52VDC, 3.94A


Power supply

AC/DC, Internal, 240W


Supported voltage range

100 to 240VAC


Management interfaces

Ethernet

Bluetooth


Networking interfaces

(1) WAN: 2.5 GbE RJ45 port

(8) LAN: 1 GbE RJ45 ports


SFP+ interfaces

(1) WAN: 10G SFP+


(1) LAN: 10G SFP+


PoE interfaces

(2) PoE+ IEEE 802.3at (pair A 1, 2+; 3, 6-)


(6) PoE IEEE 802.3af (pair A 1, 2+; 3, 6-)


Max. PoE wattage per port by PSE 802.3af

15.4W


Max. PoE wattage per port by PSE 802.3at

30W


Voltage range 802.3af mode

44 to 57V


Voltage range 802.3at mode

50 to 57V


ESD/EMP protection

Air: ± 15 kV, contact: ± 8 kV


LCM display

(1) 1.3' touchscreen


Bootup animation: bootup in progress


Firmware upgrade icon: firmware upgrading


Button

Factory reset


Operating temperature

-10 to 40° C (14 to 104° F)


Operating humidity

5 - 95% noncondensing


Certifications

CE, FCC, IC


LEDs
Ethernet

White: link/activity


SFP+

White: link/activity


HDD

White: disk activity


Amber: disk error


RPS

Blue: ready
