UBIQUITI „UniFi“ 5G (3,4 Gbps) lauko modemas su dviem SIM kortelėmis ir 2.5Gbps ryšiu „UniFi“ 5G „Max Outdoor“

High-Speed 5G

The UniFi 5G Max Outdoor is a powerful outdoor 5G modem designed to provide fast and reliable mobile internet for UniFi consoles and Cloud Gateways. It supports modern 5G NR networks with peak download speeds of up to 3.4 Gbps, while also remaining fully compatible with 4G LTE and 3G networks. This makes it suitable for a wide range of regions and mobile operators worldwide.Support for dual SIM, including Nano-SIM and eSIM, enables automatic failover between mobile operators to maintain a stable connection in case of network issues. Please note that the second Nano-SIM slot cannot be used when an eSIM is active. The device works especially well in locations where fiber is not available or where mobile connectivity is required as a primary or backup link. With support for advanced radio technologies and high transmission power, it delivers stable performance even in areas with weaker signal conditions. UniFi 5G Max Outdoor is ideal for remote sites, temporary installations, outdoor facilities, and business-critical locations that require dependable high-speed internet access.

Rugged Enclosure

UniFi 5G Max Outdoor is built to operate reliably in demanding outdoor environments. Its enclosure combines aluminum alloy with UV-stabilized polycarbonate, providing strong protection against weather, sunlight, and mechanical stress. The device is rated IPX6 by default and can reach IP67 protection when used with the optional cable-gland door kit, making it suitable for rain, snow, dust, and humidity. Flexible mounting options allow installation on walls or poles, with all required mounting accessories included in the package. The sturdy construction is engineered to withstand strong winds of up to 200 km/h, ensuring safe deployment on rooftops, towers, or open outdoor structures. Integrated cellular antennas, including high-gain antennas for downlink, help maintain strong and consistent signal reception. Power is supplied via PoE, simplifying installation by reducing the need for separate power lines. This rugged design ensures long-term stability in industrial, commercial, and remote outdoor deployments.

Easy Management

The UniFi 5G Max Outdoor is designed to work with UniFi Cloud Gateways and UniFi consoles as an external 5G modem. It connects via Ethernet and provides a high-speed mobile WAN uplink for UniFi networks. The device does not function as a standalone router, but instead complements existing UniFi infrastructure by delivering primary or backup internet connectivity. A single 2.5 GbE Ethernet port provides fast connectivity to gateways or switches, ensuring the cellular connection does not become a bottleneck. Power over Ethernet further simplifies deployment and maintenance. The device uses high-power radio technology to improve uplink performance, which is especially useful in locations with challenging network conditions. With a maximum power consumption of only 14.5 W, it remains energy-efficient while delivering enterprise-grade performance. The wide operating temperature range from -40°C to +65°C allows reliable operation in extreme climates. UniFi 5G Max Outdoor is well suited for enterprises, service providers, and organizations that require a stable, manageable, and outdoor-ready 5G connectivity solution.

Dimensions:

Device: 220 x 165 x 66.9 mm (8.7 x 6.5 x 2.6")

With mount: 220 x 165 x 122 mm (8.7 x 6.5 x 4.8")

Networking Interface:

(1) 2.5 GbE RJ45 port

5G NR and LTE radio

SIM:

(1) Nano SIM

(1) Nano-SIM or eSIM

PoE Interface: (1) PoE input

Mounting: Pole mount, wall mount (Included)

Weatherproofing:

IPX6

IP67 (With cable-gland door kit)

Mechanical

Weight:

Device: 1.2 kg (2.6 lb)

Mount: 130 g (4.6 oz)

Enclosure Material: Aluminum-alloy, UV-stabilized polycarbonate

Mount Material: UV-stabilized polycarbonate

Pole Mount Diameter: 1-2.5" (25-63.5 mm) on pipe outer diameter

Wind Loading: 91N at 200 km/h (20.45 lbf at 125 mph)

Hardware

Management: Ethernet

5G NR:

Category: 5G NR

Frequency Bands: n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n71, n75, n76, n77, n78, n79

Max. TX Power: HPUE power class 2: 26 dBm

4G LTE:

Frequency Bands: B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71

Max. TX Power: HPUE power class 2: 25 dBm

3G UMTS:

Frequency Bands: B1, B2, B4, B5, B8, B19

Peak Data Speed:

5G NSA:

Downlink 3.4 Gbps

Uplink 560 Mbps

5G SA:

Downlink 1.8 Gbps

Uplink 650 Mbps

4G LTE:

Downlink 1.6 Gbps

Uplink 210 Mbps

Antennas:

Type:

(6) Embedded cellular antennas, including

(2) high-gain for downlink: peak 9 dBi, 85°x85°

Max. Power Consumption: 14.5W

Power Method: PoE

Buttons: (1) Factory reset

LEDs: ✓

Ambient Operating Temperature: -40 to 65 °C (-40 to 149 °F)

Ambient Operating Humidity: 5 to 95% noncondensing

Certifications: CE, PTCRB, GCF
