UBIQUITI UISP jungiklis profesionalams
Prekės kodas: 18-UISP-S-Pro

UBIQUITI UISP jungiklis profesionalams


UBIQUITI UISP jungiklis profesionalams

Prekės kodas: 18-UISP-S-Pro

UBIQUITI UISP jungiklis profesionalams


Jūsų palyginimo sąraše yra 3 prekės, prašome vieną pašalinti ir bandyti dar kartą.
  • Įtraukti į patikusias prekes
  • Pridėta į patikusias prekes
  • Pašalinta iš patikusų prekių
Įtraukti į palyginimą
477,83 €
Prekė sandelyje

Garantija
12 mėn.

Pristatymas iš Lietuvos
per 2 - 4*
d. d.

Jūsų žinutė sėkmingai išsiųsta!
Užpildykite privalomus laukus*

Gigabit Layer 2 PoE switch for ISP networksIdeal for ISP deployments, the UISP™ Switch Pro is a Layer 2 PoE switch with (24) GbE RJ45 ports and (4) 1/10G SFP ports for fiber uplinks. The UISP Switch Pro is an effective solution for ISPs looking to quickly deliver Gigabit wireless speeds to their customers. With its hefty 220W total PoE supply, the UISP Switch Pro delivers substantial power to every radio in your service network. The UISP Switch Pro is managed with the UISP application, a centralized platform where you can monitor and manage all of your UISP devices.


UISP application supportBluetooth-powered setup via the UISP Mobile app is available. Thanks to UISP app you can centrally manage your networks and clients with ease. Simply organize your clients' plans, setup billing and invoicing, and grow your customer base. UISP application allows viewing network topology, advanced data analytics, quickly set up devices and manage them on the go with a powerful mobile app. Managed with the UISP application: Version 1.5.7 and later.


- (24) GbE RJ45 ports, including (16) with 27V passive PoE output

- (4) SFP+ ports

- 220W (27V) total PoE availability, 15W/port (2-pair) / 30W/port (4-pair)

- Port isolation, speed limiting, and DHCP snooping functionality

- 1.3' LCM color touchscreen

- Additional Power TransPort input for DC redundancy


Mechanical
Dimensions 442.4 x 267.5 x 43.7 mm (17.4 x 10.5 x 1.7')
Weight 4 kg (8.8 lb)
Enclosure materials SGCC steel, polycarbonate/acrylonitrile butadiene styrene
Hardware
Networking interface (24) GbE RJ45 LAN ports

(4) 1/10G SFP+ ports
Management interface Ethernet In-band

Bluetooth
Total non-blocking throughput 64 Gbps
Switching capacity 128 Gbps
Forwarding rate 95.23 Mpps
Power method (1) Universal AC input, 100-240V AC, 4.4A Max., 50/60 Hz

(1) Power TransPort DC input 27V DC, 9.3A
Power supply AC/DC, Internal, 250W
Supported voltage range 100—240V AC
Max. power consumption 30W (Excluding PoE output)
ESD/EMP protection Air: ± 15 kV, contact: ± 8 kV
LCM display (1) 1.3' touchscreen
Operating temperature -10 to 50° C (14 to 122° F)
Operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
PoE
PoE interface (16) 27V passive PoE: 2-pair (Pins 4, 5+/7, 8-) or 4-pair (Pins 1, 2, 4, 5+/3, 6, 7, 8-); Ports 1 to 16
Total available PoE 220W
Max. passive PoE wattage per port 30W/27V DC
Passive PoE voltage range 27V DC
LEDs
RJ45 data ports PoE

Speed/link/activity
SFP+ data ports Speed/link/activity
Software
Management application UISP: Version 1.5.7 and later
