Gigabit PoE switch for MicroPoP applications.


Ideal for wireless ISP (WISP) deployments, the UISP® Switch is a fanless, Layer 2 PoE switch with (8) GbE RJ45 ports and (1) 1G SFP port for an additional fiber uplink option. The UISP Switch is a cost-effective solution for WISPs looking to quickly and inexpensively deliver Gigabit wireless speeds to their customers. With its hefty 110W total PoE supply, the UISP Switch delivers substantial power to every radio in your service network. For larger deployments, pair it with the UISP Console to create a cohesive routing and switching hub. The UISP Switch is managed with the UISP application, a centralized platform where you can monitor and manage all of your UISP devices.


Features:



  • (8) GbE RJ45 ports with 27V passive PoE that support 2-pair and 4-pair modes

  • (1) 1G SFP port

  • 110W PoE supply when powered with the included AC/DC adapter

  • Fanless, thermal cooling for silent operation

  • Wall-mountable (kit included)

  • Layer 2 switching features

  • Easy, Bluetooth-powered setup via theUISPMobile app









































































































Mechanical
Dimensions

210.4 x 95 x 29 mm (8.28 x 3.74 x 1.14')


Weight

610 g (1.34 lb)


Enclosure material

Polycarbonate


Hardware
Total non-blocking throughput

9 Gbps


Switching capacity

18 Gbps


Forwarding rate

13.392 Mpps


Networking interface

(8) 10/100/1000 MbE RJ45 ports

(1) 1G SFP port


Management interface

Ethernet in-band


Bluetooth BLE


Power method

External AC/DC adapter


Power supply

27VDC, 4.4A power adapter (included)


Supported voltage range

24 - 28VDC


Max. power consumption

8W (excludes PoE output)


ESD/EMP protection

Air: ± 15 kV, contact: ± 8 kV


Operating temperature

-10 to 50° C (14 to 122° F)


Operating humidity

5 to 95% non-condensing


Certifications

CE, FCC, IC


PoE
PoE interface

(8) 27V passive PoE: 2-pair (pins 4, 5+/7, 8-) or 4-pair (pins 1, 2, 4, 5+/3, 6, 7, 8-)


Max. Passive PoE wattage per port

30W/27VDC


Passive PoE voltage range

27VDC


LEDs
System

Status


RJ45 data ports

PoE

Speed/link/activity


SFP data ports

Link/activity
