„Digitus DS-55509“ matricinis perjungiklis

Digitus 4x2 HDMI Matrix Switch, 4K/60Hz. Maximum resolution: 3840 x 2160 pixels, Bandwidth: 18 Gbit/s, Maximum resolution (HDMI): 3840 x 2160 pixels. Housing colour: Black, Housing material: Metal. USB connector type: Micro-USB, Headphone connectivity: 3.5 mm. Power consumption (max): 3.8 W, Output current: 1000 mA, Output voltage: 12 V. Country of origin: China

Switch conveniently between up to 4 HDMI sources and 2 playback devices without the trouble of replugging cables and distribute your media content independently on up to 2 playback devices in 4K UHD resolution

- Supports 4K2K/60Hz (4:4:4)
- Video bandwidth: 18 Gbps
- HDCP 2.2 / 1.4
- HDMI 2.0
- EDID management
- ARC (Audio Return Channel)
- Supports downscaling of 4K contents on Full HD (1080p) displays
- Supports Dolby Vision, HDR10+, HLG
- Audio extractor (connection of audio output device via optical/analog connection)

The Digitus® HDMI 4x Matrix Switch, 4K/60Hz distributes media content from up to 4 HDMI sources on up to 2 recording devices (e.g. hard drive recorder) or playback devices (TV, monitor, projector, etc.), simultaneously and independently. Convenient switching via remote control between the HDMI sources and output devices, independently and without the trouble of replugging cables. Thanks to 4K UHD support, you can experience your media content in ultra-high resolution. The perfect and complete HDMI distributor solution whether for professional or commercial use.

Features

Maximum resolution: 3840 x 2160 pixels
Bandwidth: 18 Gbit/s
Maximum resolution (HDMI): 3840 x 2160 pixels
Feature: HDCP
HDCP version: 1.4/2.2
Feature: Extended display identification data (EDID)
Feature: EDID management

Design

Housing colour: Black
Housing material: Metal
LED indicators: Yes

Ports & interfaces

HDMI input ports quantity: 4
HDMI output ports quantity: 2
HDMI version: 2.0
Digital audio optical in: 1
USB connector type: Micro-USB
USB ports quantity: 1
Headphone connectivity: 3.5 mm
Headphone outputs: 1
Feature: DC-in jack

Power

Power consumption (max): 3.8 W
Output current: 1000 mA
Output voltage: 12 V

Operational conditions

Operating temperature (T-T): 0 - 40 °C

Logistics data

Country of origin: China
Harmonized System (HS) code: 85299097

Technical details

Package volume: 3750.02 cm³

Weight & dimensions

Width: 251 mm
Depth: 105 mm
Height: 20 mm
Weight: 620 g
Package width: 309 mm
Package type: Box
Package depth: 164 mm
Package height: 67.3 mm
Package weight: 1.09 kg

Packaging content

Feature: Manual
Feature: Mounting brackets included
Feature: AC adapter included
