„Digitus DN-93816 Keystone“ modulis

Digitus CAT 8.1 Keystone module, shielded, tool-free mounting connection. Construction type: Flat, Product colour: White, Connector 1: RJ-45. Package width: 346 mm, Package depth: 146 mm, Package height: 188 mm. Quantity per pack: 1 pc(s). Country of origin: China

25/40GBase-T transmission speed in permanent link up to 24 m and channel link up to 30 m. Especially for ToR and MoR cabling in data centers.

- 25/40GBase-T
- 2000 MHz
- AWG 22/1 - 26/7
- Tool-free mounting connection
- Supported PoE standards: IEEE 802.3 af/at/bt - PoE, PoE+ & 4PPoE (in Permanent Link)

The item "DN-93816" from the DIGITUS® brand is a shielded CAT 8.1 keystone module with tool-free mounting connection, which offers excellent performance and connection quality for your network. The compact design allows 24 units to be installed in series in 483 mm (19") 1U panels. It is compliant with Category 8.I / 25/40GBase-T ISO/IEC 11801.

Features

Construction type: Flat
Product colour: White
Connector 1: RJ-45
Connector 2: RJ-45
Connector 1 gender: Female
Connector 2 gender: Female
Connector contacts plating: Gold
AWG wire size: 22/26
Cable types supported: Cat8.1
Housing material: Zinc
Feature: Built-in dust cover
Frequency: 2000 MHz
Feature: Magnetically shielded

Operational conditions

Operating temperature (T-T): -10 - 60 °C

Packaging data

Package width: 346 mm
Package depth: 146 mm
Package height: 188 mm
Package weight: 27.2 g

Packaging content

Quantity per pack: 1 pc(s)

Logistics data

Country of origin: China
Harmonized System (HS) code: 85369010
