ASSMANN Electronic AK-330126-200-S HDMI kabelis

ASSMANN Electronic AK-330126-200-S. Cable length: 20 m, Connector 1: HDMI Type A (Standard), Connector 1 gender: Male, Connector 2: HDMI Type A (Standard), Connector 2 gender: Male, Connector contacts plating: Gold, HDMI version: 2.1, 3D, Data transfer rate: 48 Gbit/s, Audio Return Channel (ARC), Product colour: Black

This active HDMI® AOC Hybrid Fiber Optic Cable is ideally suited for transferring uncompressed video and audio data with high bandwidth over longer distances. The hybrid construction, which uses copper and fiber optic cable, prevents electromagnetic interference. This ensures a loss-free transfer along the entire length of the cable with UHD resolution of up to 8K/60Hz and bandwidths of up to 48 Gbps. The use of fiber optic cable keeps the diameter of this active cable very low and gives it a very tight bending radius and low weight. It is ideal for use in homes, meeting rooms, and conference rooms as well as within buildings — and these are just a few of the possible uses. The simple Plug and Play installation is user-friendly; just plug it in and immediately enjoy optimal image quality. It supports numerous standards such as HDMI 2.1, HDCP 2.2 and HDR. Some of the many audio features supported are ARC, DTS-HD Master Audio and Dolby TrueHD. Cutting edge chip technology makes it possible to transfer the full HDMI® signal spectrum while also supporting uncompressed CED and EDID with very low latency.

Features

Cable length: 20 m
Connector 1: HDMI Type A (Standard)
Connector 2: HDMI Type A (Standard)
Connector 1 gender: Male
Connector 2 gender: Male
Connector 1 form factor: Straight
Connector 2 form factor: Straight
Product colour: Black
HDMI version: 2.1
Feature: 3D
Supported graphics resolutions: 7680 x 4320
Supported video modes: 1080p
Dolby technologies: DTS-HD Master Audio, Dolby TrueHD
Feature: Audio Return Channel (ARC)
Feature: HDMI Ethernet channel
Feature: HDCP
HDCP version: 2.2
Data transfer rate: 48 Gbit/s
Feature: High Dynamic Range (HDR) supported
Supported digital audio channels (uncompressed): 32
Maximum refresh rate: 60 Hz
Connector contacts plating: Gold

Operational conditions

Operating temperature (T-T): -10 - 80 °C
Operating relative humidity (H-H): 0 - 85%

Weight & dimensions

Cable diameter: 4.8 mm

Packaging data

Package width: 200 mm
Package depth: 60 mm
Package height: 200 mm
Package weight: 750 g
Quantity per pack: 1 pc(s)

Logistics data

Harmonized System (HS) code: 84733080
