Zyxel NWA55BE

Zyxel NWA55BE. 2.4 GHz, 5 GHz, Maximum data transfer rate: 5100 Mbit/s. Security algorithms: WEP, WPA, WPA2, WPA3, 802.1x RADIUS. Power over Ethernet (PoE). Product colour: White

Powerful. Secure. Wireless.

Configure, Connect, and Go — Outdoor WiFi 7 Just Got Smarter

Outdoor WiFi 7 Just Got Smarter

Thinking of upgrading to WiFi 7 for your outdoor network? The Zyxel NWA55BE is the ideal solution.
Powered by a Qualcomm quad-core CPU, the dual-radio BE5100 (2.4GHz: 2x2:2, 5GHz: 2x2:2) delivers up to 5.1Gbps WiFi 7 speeds for enterprise-grade performance. Its 2.5GbE port ensures a cost-effective, high-speed upgrade that works with your existing setup.

Rain or Shine, Stay Connected with Confidence

Built for tough outdoor conditions, the NWA55BE features IP55 weatherproofing and operates from -25°C to 65°C. The downward-facing antenna design helps protect against moisture, while the detachable antennas let users swap in alternatives to meet different coverage needs.

Dynamic Mesh for High-Performance Outdoor WiFi

Zyxel's Smart Mesh MLO technology creates dynamic wireless links between APs, extending outdoor coverage and enabling seamless inter-building connections—no cabling needed. With dual-radio backhaul, the NWA55BE outperforms traditional mesh setups, delivering higher bandwidth, lower latency, and stronger interference resistance.

Secure Authentication to Safeguard Business Networks

With support for a captive portal, IEEE 802.1X/RADIUS authentication, the NWA55BE not only offers small business users enterprise-level security to protect their networks, but also provides flexible options to customize wireless network login pages for marketing and brand recognition.

Connected - In Just a Few Clicks!

You can be connected in minutes with just a few simple clicks on the Nebula mobile app. The easy step-by-step wizard guides you through the entire installation process, and the intuitive app makes it easy to change settings as needed.

Nebula, The Intelligent Cloud Management

Nebula offers comprehensive monitoring and reporting capabilities, including real-time notifications for critical events via email or the mobile app. With Nebula, you can enjoy a streamlined experience for network installation and management without the need for additional costs for software or hardware controllers.

Features

Feature: 2.4 GHz
Feature: 5 GHz
Maximum data transfer rate: 5100 Mbit/s
Maximum data transfer rate (2.4 GHz): 688 Mbit/s
Maximum data transfer rate (5 GHz): 4324 Mbit/s
Bandwidth: 0.24 GHz
Networking standards: IEEE 802.11be, IEEE 802.11ax, IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a, IEEE 802.3at, IEEE 802.3bt
Feature: Wi-Fi Multimedia (WMM)/(WME)
Feature: Fast roaming
Feature: VLAN support
Feature: Wireless isolation
Feature: Band steering
Feature: Cellular Coexistence Filter (CCF)
Transmitting power: 26 dBmW
Receiver sensitivity: Min. Rx sensitivity up to -99 dBm
Mean time between failures (MTBF): 631165 h

Security

Security algorithms: WEP, WPA, WPA2, WPA3, 802.1x RADIUS
Feature: MAC address filtering
Feature: Auto Wireless Distribution System (WDS)

Management features

Feature: Command-line interface (CLI)
Feature: Cloud-managed
Feature: Firmware upgradeable

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1

Power

Feature: Power over Ethernet (PoE)
Power consumption (typical): 24 W

Design

Placement: Wall
Product colour: White
International Protection (IP) code: IP55

Antenna

Antenna type: External
Antenna features: Detachable antenna
Antennas quantity: 2
Antenna gain level (max): 3 dBi

Performance

Feature: Built-in processor

Certificates

Compliance certificates: Federal Communications Commission (FCC)

Weight & dimensions

Width: 308 mm
Depth: 136.4 mm
Height: 49.6 mm
Weight: 575.6 g

Packaging data

Package width: 221 mm
Package depth: 188 mm
Package height: 59 mm
Package weight: 984.5 g

Operational conditions

Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -25 - 65 °C
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 10 - 90%
