Zyxel CX4800-56F

Zyxel CX4800-56F. Switch type: Managed, Switch layer: L3. Console port: RJ-45. MAC address table: 30000 entries, Switching capacity: 4000 Gbit/s. Power connector: AC/DC. Rack mounting, Form factor: 1U

Future Proof Aggregation & Core Switch

The CX4800-56F supports a full suite of Layer 2 features, including VLAN, ACL, port aggregation, and 802.1X, to enhance security by preventing unauthorized access to cloud resources and AI workloads, optimize bandwidth for high-speed GPU data transfers, and enable dynamic, isolated workload environments in large-scale AI and cloud deployments.

Nebula, The Intelligent Cloud Management

Nebula offers comprehensive monitoring and reporting capabilities, including real-time notifications for critical events via email or the mobile app. With Nebula, you can enjoy a streamlined experience for network installation and management without the need for additional costs for software or hardware controllers.

Dedicated Networked AV Mode

The CX4800-56F features a custom-designed networked AV mode for standalone operation. It supports 10G Ethernet with pixel-perfect 4K60 video streaming in real-time, making it ideal for applications ranging from live events to XR and medical imaging. Leveraging AI intelligence, the switch simplifies the setup process by automatically configuring all necessary parameters, enabling a professional AVoIP deployment within minutes.

Management features

Switch type: Managed
Switch layer: L3
Feature: Quality of Service (QoS) support
Feature: Web-based management
Feature: Cloud-managed
Feature: ARP inspection
Feature: Configuring Location Settings (CLI)
Feature: System event log
MIB support: Y

Ports & interfaces

Basic switching RJ-45 Ethernet ports type: No
USB Type-A ports quantity: 2
Number of management ports: 1 pc(s)
Console port: RJ-45
QSFP28 ports quantity: 8
SFP28 ports quantity: 48
Power connector: AC/DC

Network

Feature: 10G support
Feature: Port mirroring
Feature: Policy-based routing
Feature: Flow control support
Feature: Link aggregation
Feature: Broadcast storm control
Feature: Spanning tree protocol
Feature: VLAN support

Data transmission

Switching capacity: 4000 Gbit/s
MAC address table: 30000 entries
Feature: Static route
Feature: Jumbo frames support
Jumbo frames: 9000
Packet buffer memory: 32 MB

Security

DHCP features: DHCP relay, DHCP server, DHCP snooping
Feature: Access Control List (ACL)
Feature: IGMP snooping
Security algorithms: SSH-2, SSL/TLS
Feature: MAC address filtering
Feature: SSH/SSL support
Feature: Loop protection

Multicast features

Feature: Multicast support

Design

Feature: Rack mounting
Form factor: 1U
Product colour: Black
Feature: Reset button
LED indicators: Yes

Performance

Memory type: RAM / Flash
Internal memory: 8000 MB
Flash memory: 64 MB
Mean time between failures (MTBF): 5900181.1 h

Power

Power source: AC/DC
Feature: Power supply included
Number of power supply units: 2

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 10 - 95%
Storage relative humidity (H-H): 10 - 95%
Heat dissipation: 1122 BTU/h

Weight & dimensions

Width: 440 mm
Depth: 489 mm
Height: 45 mm
Weight: 8.62 kg

Packaging content

Cables included: AC
Feature: Rack mount kit

Packaging data

Package type: Box
Package width: 595 mm
Package depth: 706 mm
Package height: 206 mm

Logistics data

Country of origin: Taiwan
