Ubiquiti „WaveFiber“ ONU tinklo medijos keitiklis

Ubiquiti WaveFiber ONU. Maximum data transfer rate: 2488 Mbit/s, Ethernet LAN data rates: 1000,2500 Mbit/s. Maximum transfer distance: 20000 m, Wavelength: 1490 nm, Tx power (min): 1.5 dBmW. LED indicators: LAN, Power, Status, Product colour: Black, White, Housing material: Polycarbonate (PC). Fiber optic connector: SC/APC, Connectivity technology: Wired. Input voltage: 24 V, Power consumption (max): 5 W

A GPON optical network unit with a 2.5 GbE port that delivers 1.2 Gbps uplink / 2.5 Gbps downlink speeds at distances up to 20 km.

Network

Maximum data transfer rate: 2488 Mbit/s
Ethernet LAN data rates: 1000,2500 Mbit/s
Feature: VLAN support

Performance

Maximum transfer distance: 20000 m
Wavelength: 1490 nm
Tx power (min): 1.5 dBmW
Tx power (max): 5 dBmW
Rx power (min): -8 dBmW
Rx power (max): -28 dBmW

Features

Feature: Reset button
LED indicators: LAN, Power, Status
Product colour: Black, White
Housing material: Polycarbonate (PC)

Ports & interfaces

Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 1
Fiber ports quantity: 1
Fiber optic connector: SC/APC
Power over Ethernet (PoE) ports quantity: 1

Power

Input voltage: 24 V
Power consumption (max): 5 W
Feature: Power over Ethernet (PoE)

Weight & dimensions

Width: 76.5 mm
Depth: 76.5 mm
Height: 26.4 mm
Weight: 78 g

Operational conditions

Operating temperature (T-T): -15 - 45 °C
Operating relative humidity (H-H): 10 - 90%

Certificates

Compliance certificates: CE, Federal Communications Commission (FCC), Industry Canada (IC)

Logistics data

Quantity per pack: 20 pc(s)
