Ubiquiti UniFi Flex Mini 2.5G

Ubiquiti UniFi Flex Mini 2.5G. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 5. Switching capacity: 25 Gbit/s. DC input voltage: 5 V. Power connector: USB. Power over Ethernet (PoE). Form factor: Desktop

Compact, 5-port 2.5G switch that can be powered with PoE or a USB-C adapter.

Management features

Switch type: Managed

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
2.5G Ethernet (copper) ports quantity: 5
USB Type-C ports quantity: 1
Power connector: USB

Network

Copper ethernet cabling technology: 2.5GBASE-T
Feature: Port mirroring
Feature: Flow control support
Feature: Broadcast storm control
Feature: Rate limiting

Data transmission

Switching capacity: 25 Gbit/s
Throughput: 12.5 Gbit/s
Forwarding rate: 18.6 Mpps
Feature: Jumbo frames support

Multicast features

Feature: Multicast support

Design

Form factor: Desktop
Product colour: White
Housing material: Polycarbonate (PC)
Feature: Reset button
LED indicators: Activity, Power, Progress

Performance

Minimum system requirements: UniFi Network Version 8.4.62 and later

Power

Power source: AC/DC/PoE
Feature: Power supply included
DC input voltage: 5 V
Input current: 1 A
Power consumption (max): 5 W
Power plug type: Type A

Power over Ethernet (PoE)

Feature: Power over Ethernet (PoE)
Power over Ethernet (PoE) voltage: 57 V
Power over Ethernet (PoE) power per port: 6.4 W

Other features

Networking features: STP / RSTP with priorities and port-level disable, Egress rate limit

Operational conditions

Operating temperature (T-T): -20 - 45 °C
Operating relative humidity (H-H): 10 - 90%

Weight & dimensions

Width: 117.1 mm
Depth: 90 mm
Height: 21.2 mm
Weight: 206 g

Packaging data

Feature: AC adapter included

Certificates

Compliance certificates: CE, Federal Communications Commission (FCC), Industry Canada (IC)
Certification: CE, FCC, IC
