TP-Link TL-WN823N tinklo plokštė

TP-Link TL-WN823N. Connectivity technology: Wireless, Host interface: USB, Interface: WLAN. Maximum data transfer rate: 300 Mbit/s, Top Wi-Fi standard: Wi-Fi 4 (802.11n), Wi-Fi band: Single-band (2.4 GHz). USB powered. Product colour: Black

What This Product Does
TP-LINK's 300Mbps Mini Wireless N USB Adapter TL-WN823N is designed to connect your laptop or desktop to a wireless network and enjoy high speed wireless performance. The fingertip design makes the adapter convenient and easy to carry around. What's more, the TL-WN823N features SoftAP Mode, one-button security setup, easy-to-use configuration software, making it a great choice for enjoying fast wireless network.

300Mbps Wireless N Speed - Extend Wireless Coverage
With wireless speeds of up to 300Mbps and advanced MIMO technology, the TL-WN823N provides you with a fast, reliable wireless connection for lag-free online gaming and video streaming. Better still, TL-WN823N achieves the best performance with wireless N devices, but also works seamlessly with existing IEEE 802.11b/g networks

Easy to Install
A friendly user interface utility on a CD for simple installation

Soft AP
Easily establish a high speeds Wi-Fi hotspot with just a few clicks

WPS
Easy wireless security encryption at a push of the WPS button

Ports & interfaces

Connectivity technology: Wireless
Host interface: USB
Interface: WLAN

Network

Maximum data transfer rate: 300 Mbit/s
Networking standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Feature: Wi-Fi
Wi-Fi band: Single-band (2.4 GHz)
Frequency range: 2.4 - 2.4835 GHz
Top Wi-Fi standard: Wi-Fi 4 (802.11n)
Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rates supported: 11,54,300 Mbit/s
Modulation: 16-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM
Security algorithms: 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Feature: Wake-on-LAN ready

Design

Component for: PC/Laptop
Product colour: Black
Antenna: Yes
Antenna design: Internal
Transmitting power (CE): 20 dBm
Transmitting power (FCC): 20 dBm
Feature: Plug and Play
LED indicators: Status
Operating modes: Infrastructure mode

Power

Feature: USB powered

System requirements

Mac operating systems supported: Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%

Sustainability

Feature: Sustainability compliance

Weight & dimensions

Width: 39 mm
Depth: 18.4 mm
Height: 7.87 mm

Packaging data

Package width: 138 mm
Package depth: 128 mm
Package height: 30 mm
Package weight: 80 g

Packaging content

Feature: Resource CD
Feature: Quick installation guide

Technical details

Compliance certificates: CE, Federal Communications Commission (FCC), RoHS

Logistics data

Harmonized System (HS) code: 85176990
