TP-Link Omada 28 prievadų gigabito išmanusis komutatorius su 16 prievadų PoE+
Prekės kodas: 18-SG2428LP

TP-Link Omada 28 prievadų gigabito išmanusis komutatorius su 16 prievadų PoE+

TP-Link Omada 28 prievadų gigabito išmanusis komutatorius su 16 prievadų PoE+
TP-Link Omada 28 prievadų gigabito išmanusis komutatorius su 16 prievadų PoE+
TP-Link Omada 28 prievadų gigabito išmanusis komutatorius su 16 prievadų PoE+
TP-Link Omada 28 prievadų gigabito išmanusis komutatorius su 16 prievadų PoE+
TP-Link Omada 28 prievadų gigabito išmanusis komutatorius su 16 prievadų PoE+
TP-Link Omada 28 prievadų gigabito išmanusis komutatorius su 16 prievadų PoE+

TP-Link Omada 28 prievadų gigabito išmanusis komutatorius su 16 prievadų PoE+

Prekės kodas: 18-SG2428LP

TP-Link Omada 28 prievadų gigabito išmanusis komutatorius su 16 prievadų PoE+

Jūsų palyginimo sąraše yra 3 prekės, prašome vieną pašalinti ir bandyti dar kartą.
  • Įtraukti į patikusias prekes
  • Pridėta į patikusias prekes
  • Pašalinta iš patikusų prekių
Įtraukti į palyginimą
264,61 €
Prekė sandelyje

Garantija
12 mėn.

Pristatymas iš Lietuvos
per 2 - 4*
d. d.

Jūsų žinutė sėkmingai išsiųsta!
Užpildykite privalomus laukus*

  • 16× Gigabit 802.3af/at PoE+ ports

  • 8× Gigabit non-PoE RJ45 ports and 4× Gigabit SFP slots

  • 150 W total PoE budget with up to 30 W PoE output per port*

  • Centralized cloud management via the web or the Omada app†

  • Standalone management via web, CLI, SNMP, and RMON

  • Static Routing helps route internal traffic for higher efficiency

  • VLAN, ACL, QoS, and IGMP Snooping

  • Fanless design for quiet operation

  • Durable metal casing and rackmountable design














































HARDWARE FEATURES
Interface• 16× 10/100/1000 Mbps PoE+ RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)

• 8× 10/100/1000 Mbps non-PoE RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)

• 4× Gigabit SFP Slots
Fan QuantityFanless
Physical Security Lock√
Power Supply100-240V AC, 50/60Hz
PoE Ports (RJ45)• Standard: 802.3at/af compliant

• PoE+ Ports: 16 Ports (up to 30 W PoE Output per Port)

• PoE Power Budget: 150 W*
Dimensions ( W x D x H )17.3×8.7×1.73 in (440×220×44 mm)
MountingRack Mountable
Max Power Consumption184.7 W (110V/60Hz) (with 150 W PD connected)
Max Heat Dissipation628.0 BTU/hr (110V/60 Hz) (with 150 W PD connected)





























PERFORMANCE
Switching Capacity56 Gbps
Packet Forwarding Rate41.66 Mpps
MAC Address Table8K
Packet Buffer Memory4.1 Mbit
Jumbo Frame9 KB













































SOFTWARE FEATURES
Quality of Service• 802.1p CoS/DSCP priority

• 8 priority queues

• Priority Schedule Mode: SP (Strict Priority), WRR (Weighted Round Robin)

• Queue Weight Config

• Bandwidth Control: Port/Flow-based Rating Limit

• Smoother Performance

• Storm Control: Multiple Control Modes(kbps/ratio), Broadcast/Multicast/Unknown-Unicast Control
L2 and L2+ Features• 16 IP Interfaces: Support IPv4/IPv6 Interface

• Static Routing: 32 IPv4/IPv6 Static Routes

• DHCP Server

• DHCP Relay

- DHCP Interface Relay

- DHCP VLAN Relay

• DHCP L2 Relay

• Static ARP

• Proxy ARP

• Gratuitous ARP

• Link Aggregation

• Spanning Tree Protocol

• Loopback Detection

• 802.3x Flow Control

• Mirroring

• Device Link Detect Protocol (DLDP)

• 802.1ab LLDP/ LLDP-MED
L2 Multicast• 511 IPv4, IPv6 shared multicast groups

• IGMP Snooping

• Multicast VLAN Registration (MVR)

• Multicast Filtering

• Limited IP Multicast (256 profiles and 16 entries per profile)
Advanced Features• Automatic Device Discovery†

• Batch Configuration†

• Batch Firmware Upgrading†

• Intelligent Network Monitoring†

• Abnormal Event Warnings†

• Unified Configuration†

• Reboot Schedule†
VLAN• VLAN Group: Max. 4K VLAN Groups

• 802.1Q tag VLAN

• MAC VLAN: 12 Entries

• Protocol VLAN

• GVRP

• Voice VLAN
Access Control List• Support up to 230 entries

• Time-based ACL

• MAC ACL

• IP ACL

• IPv6 ACL

• Combined ACL

• Rule Operation: Permit/Deny

• Policy Action

- Mirroring

- Redirect

- Rate Limit

- QoS Remark

• ACL Rules Binding

- Port Binding

- VLAN Binding
Security• IP-MAC-Port Binding

• AAA

• 802.1X

- Port based authentication

- MAC (Host) based authentication

- Authentication Method includes PAP/EAP-MD5

- MAB

- Guest VLAN

- Radius authentication and accountability support

• IP/IPv6-MAC Binding

- 512 Binding Entries

- DHCP Snooping

- DHCPv6 Snooping

- ARP Inspection

- ND Detection

• IP Source Guard

- 253 Entries

- Source IP+Source MAC

• IPv6 Source Guard

- 183 Entries

- Source IPv6 Address+Source MAC

• DoS Defend

• Static/Dynamic/Permanent Port Security: Up to 64 MAC addresses per port

• Broadcast/Multicast/Unicast Storm Control: kbps/ratio control mode

• Port Isolation

• Secure web management through HTTPS with SSLv3/TLS 1.2

• Secure Command Line Interface (CLI) management with SSHv1/SSHv2

• IP/Port/MAC-based access control
IPv6• IPv6 Static Routing and ACL

• IPv6 Dual IPv4/IPv6

• IPv6 Interface

• Multicast Listener Discovery (MLD) Snooping

• IPv6 neighbor discovery (ND)

• Path maximum transmission unit (MTU) discovery

• Internet Control Message Protocol (ICMP) version 6

• TCPv6/UDPv6

• IPv6 applications: DHCPv6 Client, Ping6, Tracert6, Telnet(v6), IPv6 SNMP, IPv6 SSH, IPv6 SSL, Http/Https, IPv6 TFTP
MIBs• MIB II (RFC1213)

• Bridge MIB (RFC1493)

• P/Q-Bridge MIB (RFC2674)

• Radius Accounting Client MIB (RFC2620)

• Radius Authentication Client MIB (RFC2618)

• Remote Ping, Traceroute MIB (RFC2925)

• Support TP-Link private MIBs

• RMON MIB(RFC1757, rmon 1,2,3,9)





























MANAGEMENT
Omada AppYes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Centralized Management• Omada Cloud-Based Controller

• Omada Hardware Controller

• Omada Software Controller
Cloud AccessYes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Zero-Touch ProvisioningYes. Requiring the use of Omada Cloud-Based Controller
Management Features• Web-based GUI

• Command Line Interface (CLI) through telnet

• SNMPv1/v2c/v3

• SNMP Trap/Inform

• RMON (1,2,3,9 groups)

• SDM Template

• DHCP/BOOTP Client

• Dual Image, Dual Configuration

• CPU Monitoring

• Cable Diagnostics

• EEE

• SNTP

• System Log

























OTHERS
CertificationCE, FCC
Package Contents• SG2428LP

• Power Cord

• Installation Guide

• Rackmount Kit

• Rubber Feet
System RequirementsMicrosoft® Windows® XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux.
Environment• Operating Temperature: 0-40 (32-104 );

• Storage Temperature: -40-70 (-40-158 )

• Operating Humidity: 10-90% RH non-condensing

• Storage Humidity: 5-90% RH non-condensing
