TP-Link InSight S385DPS

TP-Link InSight S385DPS. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: White, Form factor: Bullet. Lens viewing angle, horizontal: 180°, Lens viewing angle, vertical: 51°, Lens viewing angle, diagonal: 180°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.79 mm (1 / 1.79"). Sensor type (panoramic camera): CMOS

See the big picture, capture every detail. This 4K (8MP) dual‑lens stitched panoramic camera combines ultra‑low‑light ColorPro night vision, advanced analytics, and active audio‑visual deterrence to deliver broader coverage, clearer evidence, and smarter alerts for critical broader indoor and outdoor areas, like parking lots, public squares, and industrial perimeters.

Panoramic Coverage, Richer Details
Dual‑lens stitched panoramic imaging seamlessly fuses two lenses to expand the field of view, reduce blind spots, and cut the number of install points—lowering deployment costs.
4K (8MP) resolution paired with smart video enhancement boosts clarity and readability in backlight and low‑light scenes for more reliable evidence.

Color at Night for Stronger Evidence
Ultra‑low light ColorPro night vision delivers vivid color imaging in dark environments, preserving key identifiers like faces, apparel, and vehicle colors.

Smarter Detection, Precise Alerts
People & Vehicle Analytics and Human & Vehicle Classification distinguish targets to reduce false alarms; smart detection supports behaviors like intrusion, loitering, and line crossing to focus on real threats.
Red‑blue warning lights and sound alerts provide visible and audible deterrence for proactive prevention and faster on‑site intervention.

Easy Integration, Efficient Bandwidth
Audio and alarm interface enables linkage with external microphones, speakers, and sirens for a local response loop.
H.265+ compression maintains image quality while significantly reducing bandwidth and storage costs.

Built Tough for the Outdoors
IP67 weatherproofing and IK10 vandal-proof resistance ensure long‑term reliability in harsh environments with minimal maintenance.

Performance

Type: IP security camera
Placement supported: Outdoor
Connectivity technology: Wired
Maximum operating distance: 76 m
Feature: Wide Dynamic Range (WDR)
Feature: Day/night mode
Feature: Infrared (IR) cut-off filter
Feature: Remote viewing
Dynamic range: 120 dB

Design

Form factor: Bullet
Mounting type: Wall
Product colour: White
Housing material: Metal
Protection features: Waterproof
International Protection (IP) code: IP67
IK code: IK10
Feature: Weatherproof

Camera

Minimum illumination: 0 lx
Lens viewing angle, horizontal: 180°
Lens viewing angle, vertical: 51°
Lens viewing angle, diagonal: 180°
Tilt angle range: 0 - 90°
Camera shutter speed: 1/3 to 1/10000

Image sensor

Optical sensor size: 25.4 / 1.79 mm (1 / 1.79")
Feature: Progressive scan
Sensor type: CMOS

Panoramic camera

Sensor type (panoramic camera): CMOS

Lens system

Detect distance: 76 m
Observe distance: 29 m
Recognize distance: 14 m
Feature: Fixed focus
Fixed focal length: 5 mm

Night vision

Feature: Night vision
LED type: IR/White

Video

Maximum resolution: 5456 x 1520 pixels
Total megapixels: 8 MP
Video compression formats: H.264, H.264+, H.265, H.265+
Feature: Video recording
Image quality adjustment: Brightness, Contrast, Mirror, Saturation, Sharpness
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Bit rate: Main Stream: 256 Kbps to 8 Mbps, Sub-Stream: 64 Kbps to 1024 Kbps
Feature: Back Light Compensation (BLC)
Feature: Highlight Compensation (HLC)
Feature: Digital Wide Dynamic Range (DWDR)

Audio

Feature: Built-in speaker(s)
Audio system: 2-way
Audio input channels: 1.0 channels
Audio output channels: 1.0 channels
Audio formats supported: G.711 A-law
Sample rate: 8 kHz
Feature: Built-in microphone
Number of microphones: 1
Bit rate range: 0 - 64 Kbit/s

Network

Feature: Ethernet LAN
Networking standards: IEEE 802.3at
Supported network protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Feature: SIM card slot
SIM card type: MicroSIM
Feature: Live view

Storage

Compatible memory cards: MicroSD (TransFlash)
Maximum memory card size: 512 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1
Feature: DC-in jack

Security

Feature: Built-in siren
Feature: Password protection
Feature: Video motion detection
Feature: IP address filtering
Feature: HTTPS encryption
Alert notification type: Push notification
Feature: Motion sensor
Feature: Mirror
Feature: Human and vehicle targets classification
Feature: Digest authentication

Management features

Feature: Web-based management
Feature: Web browser
Feature: Cloud-managed
Feature: Reset button

Power

Power source type: DC, PoE
Power consumption (max): 18 W
Power consumption (Power over Ethernet (PoE)): 21 W
DC output voltage: 12

Operational conditions

Operating temperature (T-T): -30 - 60 °C
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%

Weight & dimensions

Width: 116 mm
Height: 90 mm
Length: 266 mm
Weight: 1.12 kg

Packaging content

Number of cameras: 1
Feature: Mounting kit
Feature: Screws included
Feature: Drilling template included
Feature: Manual
