„Synology UC3400“ NAS / saugojimo serveris

Synology UC3400. Type: NAS. Chassis type: Rack (2U). Processor family: Intel® Xeon® D, Processor model: D-1541, Processor frequency: 2.1 GHz. Internal memory: 8 GB, Internal memory type: DDR4. Total installed storage capacity: 0 TB

Reliability and High Availability
Active-active dual controllers work simultaneously to ensure zero downtime in the event of a controller failure while the non-transparent bridge (NTB) enables inter-domain communication to maximize the protection of in-flight data.

Active-Active SAN with enterprise-class performance
Designed for mission-critical environments, UC3400 is a high-availability SAN solution supporting Fibre Channel (FC) and iSCSI protocols. With over 180,000 4K random write IOPS, it supports a wide range of demanding workloads.

Virtualization-ready
Full certification for VMware, vSphere, Microsoft Hyper-V, Citrix XenServer, and OpenStack environments

Support for Windows Offloaded Data Transfer (ODX), VMware vSphere Storage APIs Array Integration (VAAI), and ALUA ensure optimized and efficient storage operations

OpenStack® Cinder support enables UC3400 to become a block-based storage component

Flexible network options
Boost network from 10GbE and dual 1GbE RJ-45 ports to 10/25 Gb Ethernet cards or 16 Gb Fibre channel host bus adapters on each controller.

Built-in data protection and security
Maximize service uptime for critical services and enhance data security with snapshot protection and self-encrypting drive support in UC3400.

Storage expansion
Simple capacity expansion of up to 576 TB of raw storage is available with two Synology RXD1219sas Expansion Units.

Performance backed by Synology drives
Leverage high sustained performance and reliability with enterprise-grade drives with built-in protection designed for Synology systems.

Storage

Storage drive capacity: 0 GB
Storage drive interface: Serial Attached SCSI (SAS)
Storage drive sizes supported: 2.5,3.5"
Feature: RAID support
RAID levels: 0, 1, 5, 10, JBOD
Feature: Hot-swap drive bays
Supported file systems: BTRFS, ext4
Total installed storage capacity: 0 TB
Number of storage drives supported: 12
Installed storage drive type: No
Supported storage drive types: HDD & SSD

Processor

Processor manufacturer: Intel
Processor family: Intel® Xeon® D
Processor model: D-1541
Processor frequency: 2.1 GHz
Processor boost frequency: 2.7 GHz
Processor cores: 8
Processor cache: 12 MB
CPU configuration (max): 1

Memory

Internal memory: 8 GB
Internal memory type: DDR4
Maximum RAM supported: 64 GB

Network

Feature: Ethernet LAN
Ethernet LAN data rates: 10,100,1000,10000 Mbit/s
Supported network protocols: SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Feature: Link aggregation

Ports & interfaces

Ethernet LAN (RJ-45) ports: 3

Design

Chassis type: Rack (2U)
Cooling type: Active
Number of fans: 2 fan(s)
Fan diameter: 6 cm

Performance

Type: NAS
Feature: Backup function
Feature: Snapshot
Feature: Access Control List (ACL)
Feature: Reset button

Power

Power supply unit (PSU) capacity: 500 W
Number of power supply units: 2
Feature: Redundant power supply (RPS) support
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz

Weight & dimensions

Width: 482 mm
Depth: 724 mm
Height: 88 mm
Weight: 19.7 kg

Processor special features

Intel Secure Key Technology version: 1.00
Intel TSX-NI version: 1.00

Operational conditions

Operating temperature (T-T): 0 - 35 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -20 - 60 °C
