„Synology RackStation RS422+“ NAS / saugojimo serveris

Synology RackStation RS422+. Type: NAS. Chassis type: Rack (1U). Device class: Home & Home Office. Processor family: Ryzen Embedded, Processor model: R1600, Processor frequency: 2.6 GHz. Internal memory: 2 GB, Internal memory type: DDR4. Operating system installed: DSM

Streamline your data management

With its compact 1U form factor and powerful Synology DiskStation Manager (DSM) operating system, the 4-bay Synology RackStation RS422+ is an affordable all-in-one solution for small businesses and home lab owners looking to meet their daily data management, sharing, synchronization, and backup needs.

Space-saving design for flexible deployment

Thanks to its compact 1U chassis, the RS422+ fits perfectly in a 2-post or wall mount rack. Deploy it in space-limited environments or anywhere else without investing in costly railkits or other server equipment.

Flexible networking options

Leverage built-in connectivity to integrate the RS422+ into any IT environment, or expand its capabilities by adding plug-and-play modules.

Built-in connectivity

Dual Gigabit ports with support for network failover and load balancing deliver fast and dependable performance out of the box.

Easy upgrade to 10GbE

Add an E10G22-T1-Mini Network Upgrade Module through the easily accessible slot to instantly enable faster networking.

All-in-one data management platform

The RS422+ is designed to support small deployments in tackling common applications such as file management, data backup, and surveillance.

Edge storage for distributed teams

Provide secure and convenient multi-platform file access, sharing, and synchronization across different locations.

Multi-endpoint data protection

Design an effective backup strategy to maximize system availability with a host of native and license-free solutions.

Smart surveillance for small deployments

Leverage flexible deployment options, intuitive management capabilities, and advanced video analytics to secure your premises.

Works best with Synology drives

Enjoy high sustained performance and reliability with enterprise-grade drives designed for Synology systems and featuring built-in data protection.

Powered by Synology DSM

Take advantage of a whole host of native productivity, management, and security solutions available on the web-based DSM operating system.

Storage

Supported storage drive interfaces: Serial ATA
Storage drive sizes supported: 2.5,3.5"
Feature: RAID support
RAID levels: 0, 1, 5, 6, 10, JBOD
Feature: Hot-swap drive bays
Supported file systems: BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
Number of storage drives supported: 4
Installed storage drive type: No
Supported storage drive types: HDD & SSD

Processor

Processor manufacturer: AMD
Processor generation: AMD Ryzen Embedded R1000 Series
Processor family: Ryzen Embedded
Processor model: R1600
Processor frequency: 2.6 GHz
Processor boost frequency: 3.1 GHz
Processor cores: 2
Processor threads: 4
On-board graphics card model: Not available

Memory

Internal memory: 2 GB
Internal memory type: DDR4
Feature: ECC

Network

Feature: Ethernet LAN
Ethernet LAN data rates: 1000 Mbit/s
Feature: Wake-on-LAN ready
Supported network protocols: SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, and VPN (PPTP, OpenVPN, L2TP)

Ports & interfaces

Feature: USB port
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
Ethernet LAN (RJ-45) ports: 2
Expansion ports quantity: 1

Design

Chassis type: Rack (1U)
Cooling type: Active
Product colour: Black
Number of fans: 3 fan(s)
Fan diameter: 4 cm
LED indicators: Yes

Performance

Type: NAS
Device class: Home & Home Office
Feature: Backup function
Number of users: 2048 user(s)
Feature: Share folder access right management
Feature: Access Control List (ACL)
Feature: Reset button
Feature: On/off switch
Browser supported: Google Chrome, Firefox, Microsoft Edge, Safari 13 and later, and Safari (iOS 13.0 and later) on iPad, Chrome (Android 11.0 and later) on tablets
Share folder: 1024

Software

Operating system installed: DSM
Operating system version: 7.1

Power

AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz

Weight & dimensions

Width: 430.5 mm
Depth: 295.5 mm
Height: 44 mm
Weight: 4.38 kg

Packaging content

Cables included: AC
Feature: Quick installation guide
Feature: Rack mount kit

Operational conditions

Operating temperature (T-T): 0 - 35 °C
Operating relative humidity (H-H): 8 - 80%
Storage temperature (T-T): -20 - 60 °C
Storage relative humidity (H-H): 5 - 95%
Operating altitude: 0 - 5000 m

Logistics data

Harmonized System (HS) code: 84714100

Other features

I/O ports: Console Port
Compliance certificates: RoHS
