StarTech.com JD089BST network transceiver module

StarTech.com HP JD089B Compatible SFP Transceiver Module - 10/100/1000BASE-TX~HPE JD089B Compatible SFP Module - 1000BASE-T - SFP to RJ45 Cat6/Cat5e - 1GE Gigabit Ethernet SFP - RJ-45 100m - HPE 5820AF, 12500, 5500. SFP transceiver type: Copper, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Product colour: Silver, Housing material: Aluminium, Mean time between failures (MTBF): 4655371 h. Power consumption (typical): 1.3 W. Compliance certificates: RoHS, Certification: CE, FCC, UR. Width: 13.7 mm, Depth: 68 mm, Height: 13.8 mm

10/100/1000 Mbps | Copper | RJ45 | 100 m (328 ft) | Lifetime Warranty

The JD089BST is an HPE JD089B compatible copper transceiver module that has been designed, programmed and tested to work with HPE® brand switches and routers. It delivers dependable 1 GbE connectivity over fiber cable, for 1000BASE-T compliant networks, with a maximum distance of up to 100 m (328 ft).

Technical Specifications:

• Maximum Data Transfer Rate: 1000 Mbps
• Type: Copper
• Connection Type: RJ45 Connector
• Maximum Transfer Distance: 100 m (328 ft)
• MTBF: 4,655,371 hours
• Power Consumption: Less than 1.3 Watts
• Digital Diagnostics Monitoring (DDM): No

This SFP copper module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.

The StarTech.com Advantage

Performance

SFP transceiver type: Copper
Maximum data transfer rate: 1000 Mbit/s
Interface type: SFP
Maximum transfer distance: 100 m
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN (RJ-45) ports: 1
Duplex system: Full
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
Digital Diagnostics Monitoring (DDM): No

Features

Product colour: Silver
Housing material: Aluminium
Hot-swap: Yes
Mean time between failures (MTBF): 4655371 h

Power

Power consumption (typical): 1.3 W

Certificates

Compliance certificates: RoHS
Certification: CE, FCC, UR

Operational conditions

Operating temperature (T-T): 0 - 70 °C
Storage temperature (T-T): -40 - 85 °C
Operating relative humidity (H-H): 5 - 95%

Weight & dimensions

Width: 13.7 mm
Depth: 68 mm
Height: 13.8 mm
Weight: 25 g

Packaging content

Quantity per pack: 1 pc(s)

Packaging data

Package width: 119 mm
Package depth: 93 mm
Package height: 35 mm
Package weight: 54 g

Logistics data

Master (outer) case width: 350 mm
Master (outer) case length: 410 mm
Harmonized System (HS) code: 85369010
Master (outer) case height: 355 mm
Products per master (outer) case: 100 pc(s)
Country of origin: China
