NETGEAR WAX620

NETGEAR WAX620. 2.4 GHz, 5 GHz, Maximum data transfer rate: 3600 Mbit/s. Security algorithms: EAP-TLS, PEAP, SSL/TLS, TTLS, WPA, WPA2, WPA3. Ethernet LAN data rates: 100,1000,2500 Mbit/s. Power over Ethernet (PoE). Product colour: White

Get powerful and reliable WiFi 6 connectivity for all your devices, even in high-density environments. Simplified enterprise-grade security and networking for the smaller business.

High-Performance Business WiFi
Faster and more reliable dual band WiFi 6 with 8 streams and up to 2.4Gbps in 5GHz band and 1.2Gbps in 2.4GHz band

Ideal for High Density Environments
Ultimate WiFi performance for schools, hotels, restaurants, and conference centers.

Greater Network Capacity
Enjoy 4x more connection capacity than your current WiFi and improved efficiency for longer battery life.

Seamless Wireless Mesh
Wire-free installation with other WAX620, WAX610, WAX610Y, WAC540, or WAC564 creates the perfect seamless business network.

Multi-Gigabit Speed
Includes a 2.5 Gbps Ethernet port with PoE for high speed wired network connectivity and easy wiring

Easy Setup
Set up, configure, and manage with NETGEAR Insight

Flexible Mounting
Easy to securely install on the wall of a suspended ceiling with the hardware included

Business-Level Security
WPA3 for the highest level of WiFi connection security

8 Wireless Networks (SSIDs)
Separate and secure networks for admin, guests, employees and IoT devices like cameras, locks and more

Separate VLANs
Keep admin, employee, visitor, HR, Finance department networks safely separated from each other

Features

Feature: 2.4 GHz
Feature: 5 GHz
Maximum data transfer rate: 3600 Mbit/s
Maximum data transfer rate (2.4 GHz): 1200 Mbit/s
Maximum data transfer rate (5 GHz): 2400 Mbit/s
Ethernet LAN data rates: 100,1000,2500 Mbit/s
Networking standards: IEEE 802.11ax, IEEE 802.11i, IEEE 802.3af, IEEE 802.3at
Feature: Auto MDI/MDI-X
Feature: MIMO
MIMO type: Multi User MIMO
Modulation: OFDM
Feature: Wi-Fi Multimedia (WMM)/(WME)
Feature: VLAN support

Security

Security algorithms: EAP-TLS, PEAP, SSL/TLS, TTLS, WPA, WPA2, WPA3
Feature: MAC address filtering
Feature: Auto Wireless Distribution System (WDS)

Management features

Feature: Web-based management

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1
Feature: DC-in jack

Power

Feature: Power over Ethernet (PoE)
Output voltage: 12 V
Output current: 2.5 A

Design

Placement: Ceiling, Wall
Product colour: White
LED indicators: LAN, Power, WLAN

Antenna

Antenna type: Internal
Antenna gain level (max): 4.3 dBi

Weight & dimensions

Width: 205.7 mm
Depth: 205.7 mm
Height: 34.3 mm
Weight: 783 g

Packaging content

Quantity per pack: 1 pc(s)
Feature: Mounting kit
Feature: Quick start guide

Operational conditions

Operating temperature (T-T): 0 - 40 °C

Logistics data

Harmonized System (HS) code: 85176990
