NETGEAR GSM4230P

NETGEAR GSM4230P. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 30. Power over Ethernet (PoE). Rack mounting, Form factor: 1U

Pre-configured for out-of-the-box use
NETGEAR IGMP Plus™ enables instant multicast functionality for most AV over IP installations
Dedicated AV web-based GUI interface
Unique interface designed for the AV professional with color-coded, port-based profiles
Profiles for common audio protocols
Quickly assign profiles to ports for Dante, AES67, and AVB audio configurations. AVB Requires a separate license
Video profiles built-in
Special profiles for NVX, SVSI, Q-SYS and Dante video profiles can be easily assigned to ports as needed
Unique Automatic Configuration
Auto-trunk and auto-lag functionality automatically configures other M4250 switches for use in star topology.

Multi-switch audio or single-switch video deployments
24x1G PoE+ with 300W PoE budget with 2x1G additional ports and 4xSFP 1G fiber uplinks

Layer 2/Layer 3 Switching
Common Layer 2 and Layer 3 switching engine across all M4250 models

Control methods abound
Built-in IT web GUI, console, telnet and SSH consistent with other NETGEAR M4xxx series

Standard network features
Feature set includes static, RIP and PIM routing, DHCP Server and PTPv2

Management features

Switch type: Managed
Switch layer: L2/L3

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 30
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 4

Data transmission

Feature: Jumbo frames support
Jumbo frames: 12000

Design

Feature: Rack mounting
Form factor: 1U
Product colour: Black

Performance

Noise level: 34 dB
Feature: Fanless

Power

Feature: Power supply included
Power consumption (typical): 401 W

Power over Ethernet (PoE)

Feature: Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 24
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 300 W

Weight & dimensions

Width: 440 mm
Depth: 257 mm
Height: 43.2 mm
Weight: 4.3 kg

Packaging content

Cables included: AC, LAN (RJ-45), USB Type-C
Feature: User guide

Packaging data

Feature: Rack rails

Logistics data

Harmonized System (HS) code: 85176990
