„LevelOne USB-0423“ tinklo plokštė

LevelOne USB-0423. Connectivity technology: Wired, Host interface: USB Type-A/USB Type-C, Interface: Ethernet. Maximum data transfer rate: 2500 Mbit/s. USB powered. Product colour: Grey

The LevelOne USB-0423 2.5 Gigabit Ethernet 2-in-1 USB-C/A Network Adapter allows you to connect to the internet easily through the built-in USB-C/A port on your laptop. This is an ideal solution for MacBook or other Windows computers that may have wireless built-in but don't come with an Ethernet port. Sometimes you need to physically connect to a network cable to help transfer files or access secure information. The USB-0423 offers steady and efficient data transmission, with transfer speeds of up to 5Gbps. With its 2.5 Gigabit Ethernet connection, it enables lightning-fast data transfers, at speeds 2.5 times faster than Gigabit Ethernet.

The USB-0423 is USB3.0, USB3.1 Gen 1 and USB3.2 Gen 1 compliant. It also follows the Ethernet standards set by the IEEE 802.3bz, allowing you to take advantage of Gigabit Ethernet speeds of up to 2500Mbps. This provides a strong backbone for any high-speed broadband connection to the internet as well as fast speeds for the Local Area Network file transfers.

This makes the USB-0423 the best choice for reliability, efficiency and standard compliance.

Ports & interfaces

Connectivity technology: Wired
Host interface: USB Type-A/USB Type-C
Interface: Ethernet
Ethernet LAN (RJ-45) ports: 1
USB version: 3.2 Gen 1 (3.1 Gen 1)

Network

Maximum data transfer rate: 2500 Mbit/s
Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Feature: Ethernet LAN
Ethernet interface type: 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000,2500 Mbit/s
Cabling technology: 10/100/1000BaseT(X)
Feature: Wake-on-LAN ready
Feature: Full duplex
Feature: Jumbo frames support
Jumbo frames: 16000

Design

Component for: Laptop
Product colour: Grey
Feature: Plug and Play
LED indicators: Activity, Link
Country of origin: China

Power

Feature: USB powered

System requirements

Windows operating systems supported: Yes
Mac operating systems supported: Yes
Linux operating systems supported: Yes
Other operating systems supported: Android, iOS

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 80%

Sustainability

Feature: Sustainability compliance

Weight & dimensions

Width: 59 mm
Depth: 25 mm
Height: 14 mm
Weight: 35 g

Packaging data

Package width: 158 mm
Package depth: 85 mm
Package height: 22 mm
Package weight: 57 g

Packaging content

Feature: Quick installation guide

Technical details

Compliance certificates: CE, RoHS, UKCA
