„LevelOne POW-4821“ maitinimo blokas

LevelOne 48V DC Industrial Power Supply, 75W, DIN-Rail, PoE Ready. Total power: 75 W, AC input voltage: 90 - 264 V, Peak power: 76.8 W. Mean time between failures (MTBF): 506600 h. Product colour: Mint colour, Silver. Safety: UL508, TUV EN60950-1, EAC TP TC 004, BSMI CNS14336-1 approved;(meet EN60204-1). Width: 125.2 mm, Depth: 102 mm, Height: 32 mm

The POW-4820 is a DIN-rail industrial power supply is ruggedized, universal input voltage range and full compliance with all important safety and EMC standards. It can be operated at full load across an ambient temperature range of -20 to 60 Celsius degree without need of additional cooling to guarantee quality for harsh industrial environment. Moreover, this power unit has been designed specifically for use with Infinity Industrial PoE Ethernet series, also it meets the requirements for both PoE and PoE Plus as well.

Power

Total power: 75 W
Peak power: 76.8 W
AC input voltage: 90 - 264 V
Power protection features: Over voltage, Overload, Short circuit

Performance

Mean time between failures (MTBF): 506600 h

Design

Product colour: Mint colour, Silver
LED indicators: Yes

Operational conditions

Operating temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 20 - 95%

Safety regulation & standards

Safety: UL508, TUV EN60950-1, EAC TP TC 004, BSMI CNS14336-1 approved;(meet EN60204-1)

Weight & dimensions

Width: 125.2 mm
Depth: 102 mm
Height: 32 mm
Weight: 510 g

Packaging data

Package width: 125.2 mm
Package depth: 102 mm
Package height: 32 mm
Package weight: 510 g

Logistics data

Harmonized System (HS) code: 84733020
Country of origin: China

Other features

Maximum current: 1.6 A
Feature: Power over Ethernet (PoE)
Technical features: 48V DC Out
