Highly intuitive, the Smart Managed Switch can manage local networks. With the DoLynk Care platform, it can also perform cloud management. The switch performs operation and maintenance using topology visualization on front-end, transmission and back-end storage devices that are in the security system and IT system. With its full metal design, the switch has great heat dissipation and can operate in temperatures ranging -10°C to 55°C. It offers EMC and has protection against overvoltage, overcurrent, static electricity, lightning strikes, pulses and other types of interference. For the PoE series Smart Managed Switch, power is supplied up to 250 meters away. The orange port supplies up to 60 W and the red port provides up to 90 W. Also, link aggregation and STP are available on select models to ensure
the network remains stable. The switch can be used in small and medium-sized businesses such as supermarkets, offices, restaurants, cafés and hotels.
| 10G support | No |
| Basic switching RJ-45 Ethernet ports quantity | 6 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Cloud-managed | Yes |
| Copper ethernet cabling technology | 1000BASE-T/100BASE-TX/10BASE-T |
| DC input voltage | 53 V |
| Depth | 90 mm |
| DHCP features | DHCP client |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Flow control support | Yes |
| Forwarding rate | 8.93 Mpps |
| Full duplex | Yes |
| Gigabit Ethernet (copper) ports quantity | 6 |
| Height | 26 mm |
| Housing material | Metal |
| Input current | 1.226 A |
| Jumbo frames | 15000 |
| Jumbo frames support | Yes |
| LED indicators | Yes |
| Link aggregation | Yes |
| MAC address table | 8000 entries |
| Model name | DH-CS4006-4GT-60 |
| Networking standards | IEEE 802.3/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3u/IEEE 802.3x |
| Number of VLANs | 32 |
| Operating relative humidity (H-H) | 5 - 95 % |
| Operating temperature (T-T) | -10 - 55 °C |
| Package depth | 238 mm |
| Package height | 76 mm |
| Package weight | 940 g |
| Package width | 265 mm |
| Power consumption (max) | 65 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 4 |
| Power source | DC |
| Product colour | Black |
| Quality of Service (QoS) support | Yes |
| Reset button | Yes |
| Spanning tree protocol | Yes |
| Storage relative humidity (H-H) | 5 - 95 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Summary | Dahua Technology DH-CS4006-4GT-60. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 6. Full duplex. MAC address table: 8000 entries, Switching capacity: 12 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x. DC input voltage: 53 V. Power over Ethernet (PoE). Wall mountable |
| Switch layer | L2 |
| Switch type | Managed |
| Switching capacity | 12 Gbit/s |
| Unit Box Height | 0.085 |
| Unit Box Length | 0.115 |
| Unit Box Width | 0.2 |
| Unit Calculated Volume | 0.002527 cubm |
| Unit Calculated Weight | 0.783 kg |
| Units per Shipping Box | 12 |
| Vendor Homepage | https://www.dahuasecurity.com/products/All-Products/Transmission/Cloud-Managed-Switches/CS4006-4GT-60 |
| Virtual LAN features | Port-based VLAN |
| VLAN support | Yes |
| Wall mountable | Yes |
| Web-based management | Yes |
| Weight | 290 g |
| Width | 130 mm |
