Intellinet 561235 PoE adapteris

Intellinet Gigabit Ultra PoE+ Injector, 1 x 60 W Port, IEEE 802.3bt and IEEE 802.3at/af Compliant, Plastic Housing. Ethernet interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x. Product colour: Black. Power over Ethernet (PoE) voltage: 48 V, AC adapter input voltage: 100 - 240 V, AC adapter frequency: 50/60 Hz. Compliance certificates: CE, RoHS, Federal Communications Commission (FCC), UL, Certification: FCC , CE. Width: 61 mm, Depth: 123 mm, Height: 40 mm

60 Watts of Power for the Internet of things (IoT)!
The Intellinet Network Solutions Gigabit High-Power PoE Injector provides up to 60 W using all four pairs of twisted-pair Cat5 or Cat6 cabling to support IoT applications such as lighting, sensors and building automation. Nurse call systems require 30 to 50 watts of power. Point-of-sale card readers & printers need up to 60 watts. Lighting fixtures and controllers require 40 to 50 watts. Thin clients draw up to 50 watts. Ultra PoE standard is an excellent solution for bringing power to these important, critical systems. As many new powered devices enter the market, you'll be ready for them with an Intellinet Network Solutions Gigabit High-Power PoE Injector.

Full Compatibility with Existing IEEE 802.3af/at PoE Powered Devices
The Intellinet Network Solutions Gigabit High-Power PoE Injector allows you to connect your IEEE 802.3af/at-compliant products to a non-PoE LAN switch port. The injector can be used to connect a wireless access point, IP phone, network camera or any IEEE 802.3af/at-powered device (PD) to a switch.

Reduced Wiring Costs
It's no longer necessary to run AC power lines for your wireless access point, network camera or IP phone. Simply connect the PoE Injector to the LAN switch port, and use the existing Cat5 cabling to deliver DC power as well as transfer data.

Protect Your Equipment
Once DC power is connected to your networked equipment through the Cat5e/6 cabling, the Intellinet Network Solutions PoE Injector ensures that your products are protected from power problems like short circuits (short GRND), current overloads and high voltages.

Network

Ethernet interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
Feature: Power over Ethernet (PoE)
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Duplex system: Full
Cable types supported: Cat5e

Features

Product colour: Black

Ports & interfaces

Ethernet LAN (RJ-45) ports: 2

Power

Power over Ethernet (PoE) voltage: 48 V
AC adapter input voltage: 100 - 240 V
AC adapter frequency: 50/60 Hz
Output current: 1.25 A
Power consumption (max): 60 W

Certificates

Compliance certificates: CE, RoHS, Federal Communications Commission (FCC), UL
Certification: FCC , CE

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating temperature (T-T): 32 - 104 °F
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -20 - 80 °C

Weight & dimensions

Width: 61 mm
Depth: 123 mm
Height: 40 mm
Weight: 290 g

Packaging content

Number of products included: 1 pc(s)
Feature: Power cord included
Feature: Manual

Logistics data

Harmonized System (HS) code: 85044095
