„Intel Wi-Fi 7 BE202“

Intel Wi-Fi 7 BE202. Internal. Connectivity technology: Wireless, Host interface: M.2, Interface: WLAN / Bluetooth. Maximum data transfer rate: 2400 Mbit/s, Top Wi-Fi standard: Wi-Fi 7 (802.11be), Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 6 GHz). Antenna type: 2x2

Orthogonal Frequency-Division Multiple Access (OFDMA)
Orthogonal Frequency-Division Multiple Access (OFDMA) is a multi-user version of the popular orthogonal frequency-division multiplexing (OFDM) digital modulation scheme. This allows simultaneous low-data-rate transmission from several users.

Ports & interfaces

Connectivity technology: Wireless
Host interface: M.2
Interface: WLAN / Bluetooth

Network

Maximum data transfer rate: 2400 Mbit/s
Feature: Wi-Fi
Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Security algorithms: AES-CCMP, AES-GCMP, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA2, WPA3
Feature: MU-MIMO
Feature: Bluetooth
Bluetooth version: 5.4

Design

Component for: PC/Laptop
Feature: Internal
Antenna type: 2x2

System requirements

Windows operating systems supported: Windows 10, Windows 11
Linux operating systems supported: Yes

Operational conditions

Operating temperature (T-T): 0 - 80 °C

Sustainability

Feature: Sustainability compliance

Weight & dimensions

Width: 22 mm
Depth: 30 mm
Height: 2.4 mm
Weight: 3.07 g

Technical details

Compliance certificates: CB, UL

Logistics data

Harmonized System (HS) code: 8517620090

Other features

Launch date: Q3'23
Status: Launched
Ethernet adapter ARK ID: 234444
Export Control Classification Number (ECCN): 5A992C
Commodity Classification Automated Tracking System (CCATS): 740.17B1
