„Intel Killer Wi-Fi 7 BE1750i“

Intel Killer Wi-Fi 7 BE1750 i. Internal. Connectivity technology: Wireless, Host interface: M.2, Interface: WLAN / Bluetooth. Maximum data transfer rate: 5800 Mbit/s, Top Wi-Fi standard: Wi-Fi 7 (802.11be), Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 6 GHz). Antenna type: 2x2

The Intel® Wi-Fi 7 BE201, a CRF (Companion RF) adapter, is designed to support the upcoming IEEE 802.11be standard - Wi-Fi 7 technology and the Wi-Fi Alliance Wi-Fi 7 certification. This Wi-Fi/ Bluetooth® module supports dual-stream Wi-Fi in the 2.4GHz, 5GHz and 6GHz bands as well as Bluetooth® 5.4. These new features maximize the benefits of Wi-Fi 7, including up to 5 Gigabit speed, ultra-low latencies, and enhanced reliability across new radio frequencies exclusive to Wi-Fi 7 devices, and deliver a significant improvement in user experience in dense deployments, as well as extended operating range for Bluetooth® connected devices, and support for Bluetooth® LE audio. Combined with Intel® Core™ processors and exceptional Intel® wireless innovations, the Intel® Wi-Fi 7 BE201 module can dramatically improve your connected experience at home, work, or on the go.

Ports & interfaces

Connectivity technology: Wireless
Host interface: M.2
Interface: WLAN / Bluetooth

Network

Maximum data transfer rate: 5800 Mbit/s
Feature: Wi-Fi
Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Security algorithms: 128-bit AES, 256-bit AES, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA2, WPA3-Enterprise, WPA3-Personal
Feature: Bluetooth
Bluetooth version: 5.4

Design

Component for: Laptop
Feature: Internal
Antenna type: 2x2
Form factor: M.2 2230

System requirements

Windows operating systems supported: Windows 10, Windows 11
Linux operating systems supported: Yes

Operational conditions

Operating temperature (T-T): 0 - 50 °C
Operating relative humidity (H-H): 0 - 90%

Weight & dimensions

Width: 22 mm
Depth: 30 mm
Height: 2.42 mm
Weight: 3.06 g

Other features

Feature: Bluetooth Low Energy (BLE)
Launch date: Q2'24
Status: Launched
Ethernet adapter ARK ID: 230083
Export Control Classification Number (ECCN): 5A991.B
