„Grandstream Networks“ GWN7670LR belaidis prieigos taškas

Grandstream Networks GWN7670LR. 2.4 GHz, 5 GHz, Maximum data transfer rate: 3600 Mbit/s. Security algorithms: WPA, WPA2, WPA2-PSK, WPA3, WPA3-SAE. Ethernet LAN data rates: 2500 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 15.5 W

The GWN7670LR is a long-range Wi-Fi 7 access point, ideal for medium-to-large businesses that need to provide long-range coverage.

State-of-the-Art Wi-Fi 7 Connectivity
The GWN7670LR is built on Wi-Fi 7, which provides faster speeds, lower latency, and increased capacity compared to previous Wi-Fi standards.

Ideal for Environments with Medium User Density
The GWN7670LR provides speeds up to 3.6Gbps while supporting up to 256 clients per AP, making it ideal for environments with medium user density.

Twice as Fast as Wi-Fi 6
Wi-Fi 7 channels are twice the size of Wi-Fi 6 channels, allowing Grandstream's Wi-Fi 7 APs to provide maximum speeds and capacity.

Easy and Free Management
Manage Grandstream Wi-Fi APs for free from the cloud (GDMS), software (GWN Manager), app (GDMS app), and the AP itself using its built-in controller.

Free Network Management Options
GDMS Networking
GDMS Networking is an enterprise-grade, cloud management platform for Grandstream networking products.

GWN Manager
GWN Manager is an on-premise enterprise- grade, management platform for an unlimited number of Grandstream networking products.

Embedded Controller
Grandstream's GWN networking products include an embedded controller software and is built-in to the product's web user interface.

Features

Feature: 2.4 GHz
Feature: 5 GHz
Maximum data transfer rate: 3600 Mbit/s
Maximum data transfer rate (2.4 GHz): 688 Mbit/s
Maximum data transfer rate (5 GHz): 2882 Mbit/s
Ethernet LAN data rates: 2500 Mbit/s
Number of simultaneously connected devices (max): 256
Feature: Bluetooth
Bluetooth version: 5.3
Feature: Bluetooth Low Energy (BLE)
Feature: MIMO
Feature: Wi-Fi Multimedia (WMM)/(WME)
Feature: Wi-Fi roaming
Feature: VLAN support
Virtual LAN features: MAC address-based VLAN, SSID-based VLAN assignment
Feature: Rate limiting
Feature: Wireless meshing
Feature: Band steering
Feature: Maximal-Ratio Combining (MRC)
Feature: Dynamic Frequency Selection (DFS)
Feature: Quality of Service (QoS) support
Feature: BeamForming

Security

Security algorithms: WPA, WPA2, WPA2-PSK, WPA3, WPA3-SAE
Feature: MAC address filtering
Number of SSID supported: 32
Feature: Network address translation (NAT)
Feature: Wireless Intrusion Detection System (WIDS)
Feature: Remote Authentication Dial-In User Service (RADIUS)

Protocols

Feature: DHCP server
Feature: DHCP client
Management protocols: TR-069, SNMP

Management features

Feature: Web-based management

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1
WAN connection: Ethernet (RJ-45)

Power

Feature: Power over Ethernet (PoE)
Power over Ethernet (PoE) type supported: PoE+
Power consumption (max): 15.5 W

Design

Placement: Pole, Wall
Product colour: White
Feature: Reset button
LED indicators: Yes

Antenna

Antenna type: Internal & external
Antenna direction type: Directional
Antenna gain level (max): 13.5 dBi

Certificates

Compliance certificates: CE, Federal Communications Commission (FCC), Industry Canada (IC), RCM

Weight & dimensions

Width: 223.2 mm
Depth: 53.9 mm
Height: 169.9 mm
Weight: 1.2 kg

Packaging data

Package weight: 2.7 kg

Packaging content

Quantity per pack: 1 pc(s)
Feature: Mounting kit
Feature: Quick start guide

Operational conditions

Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -30 - 60 °C
Storage temperature (T-T): -40 - 70 °C
