„Fanvil i55A“ vaizdo domofono sistema

Fanvil i55A. Display diagonal: 17.8 cm (7"), Display technology: LCD, Display resolution: 1024 x 600 pixels. Speaker power: 2 W, Voice codecs: CNG, G.711a, G.711u, G.722, G.729ab, PLC, VAD, iLBC. Product colour: Stainless steel, Control type: Buttons, Placement supported: Horizontal. Compatible memory cards: MicroSD (TransFlash). Ethernet interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Cabling technology: 10/100Base-T(X)

Fanvil i55A indoor station features a 7-inch color touch screen with an intuitive UI. Based on Android 9.0 operating system, it can meet industry application customization needs and secondary development. Featuring powerful functionalities like remote door opening and real-time monitoring for security devices, i55A can serve as a management assistant for communities, villas and office buildings.

Technical details

Connectivity technology: Wired
Feature: Colour
Feature: Speakerphone
Number of displays supported: 1
Feature: Echo cancellation
Feature: Wall mountable
Feature: Built-in microphone
Video codecs: H.264
Number of buttons: 5 buttons

Display

Display diagonal: 17.8 cm (7")
Display technology: LCD
Display resolution: 1024 x 600 pixels

Audio

Feature: Built-in speaker(s)
Number of speakers: 1
Speaker power: 2 W
Voice codecs: CNG, G.711a, G.711u, G.722, G.729ab, PLC, VAD, iLBC

Design

Product colour: Stainless steel
Control type: Buttons
Placement supported: Horizontal
Proper use: Indoor

Storage

Feature: Memory card slot
Compatible memory cards: MicroSD (TransFlash)

Network

Ethernet interface type: Fast Ethernet
Ethernet LAN data rates: 10,100 Mbit/s
Ethernet LAN (RJ-45) ports: 1
Feature: Wi-Fi
Feature: Bluetooth
Cabling technology: 10/100Base-T(X)
Feature: Power over Ethernet (PoE)

Management features

Feature: Web-based management
Feature: Static IP

Power

AC adapter output voltage: 12 V
AC adapter output current: 1 A

Operational conditions

Operating temperature (T-T): -10 - 50 °C
Operating relative humidity (H-H): 10 - 90%

Weight & dimensions

Width: 217 mm
Depth: 124 mm
Height: 21 mm

Packaging data

Feature: Indoor unit included
Package width: 257 mm
Package depth: 175 mm
Package height: 76 mm

Logistics data

Quantity per pack: 1 pc(s)
