„Edimax GS-1005E“ tinklo komutatorius

Edimax GS-1005E. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 2000 entries, Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x. DC input voltage: 5 V. Wall mountable

Easily Upgrade or Expand Networks with Gigabit High-Speed
For Home, Small Office and Enterprise

5-Port Gigabit Desktop Switch
GS-1005E
Offers high-flexibility and high-bandwidth Gigabit connectivity and delivers up to 2000Mbps of throughput per port at full-duplex mode to servers, workstations and other attached devices for large files transfer. Supports 9K jumbo frames to improve network utilization in large files transfer.

Easy Plug & Play, No Installation Required
The Gigabit switch features with Flow Control, Full-Duplex, Auto-Negotiation, No-Blocking Wire Speed, Auto-MDI/MDI-X, Store-and-Forward Architecture filters fragment & CRC error packets, maximizing network performance while offering reliable connection.

High Performance and Reliable Connection
The Gigabit switch features with Flow Control, Full-Duplex, Auto-Negotiation, No-Blocking Wire Speed, Auto-MDI/MDI-X, Store-and-Forward Architecture filters fragment & CRC error packets, maximizing network performance while offering reliable connection.

Energy Efficient and Power Saving
To comply with the IEEE802.3az Energy Efficient Ethernet standard and feature with Inactive Link Detection and Cable Length Detection, the GS-1008E V2 provides power-saving functionality to reduce energy consumption and save power usage costs.

Quiet Fanless, Flexible Wall-Mount Design
Flexible deployment options for desktop or wall-mount with quiet fanless, durable metal case design to meet the network environment requirement.

Designed to meet your network needs
Easily upgrade or expand your network with Gigabit high-speed and with cost efficiency.

Management features

Switch type: Unmanaged

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)

Network

Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x

Data transmission

Switching capacity: 10 Gbit/s
Forwarding rate: 7.44 Mpps
MAC address table: 2000 entries
Feature: Jumbo frames support
Jumbo frames: 9000
Transmission method: Store and forward
Packet forwarding rate (1 Gbps): 1448000 pps
Packet forwarding rate (100 Mbps): 148800 pps
Packet forwarding rate (10 Mbps): 14880 pps
Packet buffer memory: 0.128 MB

Design

Product colour: Black
Housing material: Metal
LED indicators: Activity, Link, Power
Feature: Wall mountable

Performance

Feature: Fanless

Power

Feature: Power supply included
DC input voltage: 5 V
Input current: 1 A
Power consumption (max): 2.4 W

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%

Weight & dimensions

Width: 121 mm
Depth: 75 mm
Height: 26 mm
Weight: 229 g

Certificates

Certification: CE, FCC

Logistics data

Harmonized System (HS) code: 85176990
