„Cisco SFP-10G-LR-S“ tinklo siųstuvo-siųstuvo modulis

Cisco 10GBASE-LR S-Class SFP Module for 10-Gigabit Ethernet Deployments, Hot Swappable, 5-Year Standard Warranty (SFP-10G-LR-S=). SFP transceiver type: Fiber optic, Maximum data transfer rate: 10000 Mbit/s, Interface type: SFP+. Certification: MSA. Width: 13.4 mm, Depth: 56.5 mm, Height: 8.5 mm. Quantity per pack: 1 pc(s). Package width: 143 mm, Package depth: 158.8 mm, Package height: 44.5 mm

The Cisco 10GBASE-LR-S SFP Module delivers a wide variety of 10-Gigabit Ethernet connectivity options for data centre, enterprise and service provider applications over single-mode fibre. This hot-swappable input/output transceiver plugs into an Ethernet SFP+ port of a Cisco switch and offers optical interoperability with 10GBASE XENPAK, 10GBASE X2 and 10GBASE XFP interfaces on the same link.

Performance

SFP transceiver type: Fiber optic
Maximum data transfer rate: 10000 Mbit/s
Interface type: SFP+
Feature: Single-mode fiber (SMF) supported
Fiber optic connector: LC, PC
Fiber cable diameters supported (core/cladding): 9/125 µm
SFP transceiver standard: LR
Maximum transfer distance: 10000 m
Wavelength: 1310 nm
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u
Cabling technology: 10GBASE-LR
Duplex system: Full
Feature: Auto MDI/MDI-X

Features

Feature: Hot-Plug support

Certificates

Certification: MSA

Operational conditions

Operating temperature (T-T): -40 - 85 °C
Storage temperature (T-T): -40 - 85 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%

Weight & dimensions

Width: 13.4 mm
Depth: 56.5 mm
Height: 8.5 mm

Packaging content

Quantity per pack: 1 pc(s)

Packaging data

Package width: 143 mm
Package depth: 158.8 mm
Package height: 44.5 mm
Package weight: 90.7 g

Logistics data

Harmonized System (HS) code: 85369010
Country of origin: China
