Axis P3285-LVE

Axis P3285-LVE. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: Black, White, Form factor: Dome. Minimum illumination: 0.02 lx, Angle of rotation: 190°, Lens viewing angle, horizontal: 100°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Lens diameter: 1 cm, Focal length range: 3.4 - 9.8 mm, Detect distance (wide): 48 m

Excellent image quality

AXIS P3285-LVE offers excellent image quality and forensic details in 2 MP under any light conditions. Thanks to Lightfinder 2.0 and Forensic WDR, it ensures true colors and great detail in near darkness or challenging light. And OptimizedIR enables surveillance in pitch darkness without the need for extra lighting. Axis Zipstream with support for AV1, H.264, and H.265 significantly reduces bandwidth and storage requirements without compromising image quality. Furthermore, this dome camera is available with either a high-performing and light-sensitive 10 mm lens or a powerful and flexible 29 mm tele lens for surveillance from a distance.

Powerful analytics

Featuring a deep learning processing unit (DLPU), this AI-based camera runs advanced features and powerful analytics on the edge. It comes with AXIS Object Analytics preinstalled to detect, classify, track, and count humans, vehicles, and types of vehicles. Now combined with ARTPEC 9, this application offers enhanced performance with greater accuracy. With an acoustic sensor and support for AXIS Audio Analytics, you be notified whenever something relevant happens, even when there's no visual indication. For instance, it can detect screams, shouts, as well as changes in sound level. Additionally, AXIS Live Privacy Shield makes it easy to remotely monitor activities while protecting privacy.

Robust with strong security

This robust, IK10-, IP66-, and NEMA 4X-rated outdoor-ready camera is both vandal- and impact-resistant. It has an operating temperature range from -40°C to 50 °C (-40°F to 122°F). And a built-in intrusion switch can detect tampering. Axis Edge Vault, our hardware-based cybersecurity platform, safeguards the device and protects sensitive information from unauthorized access. It also offers secure key storage with FIPS 140-3 Level 3 certified secure cryptographic key storage and operations. What's more, this dome camera is easy to install, maintain, and operate.

Performance

Type: IP security camera
Placement supported: Indoor & outdoor
Connectivity technology: Wired
Feature: PTZ control
PTZ modes: Digital PTZ
Feature: Auto-tracking
Feature: Tour recording
Feature: Wide Dynamic Range (WDR)
Feature: Day/night mode
Certification: UL/cUL, CE, KC, EAC, VCCI, RCM, ICES, UKCA, FCC

Design

Form factor: Dome
Mounting type: Ceiling/wall
Product colour: Black, White
LED indicators: Yes
Housing material: Plastic, Polycarbonate (PC)
Protection features: Impact resistant, Vandal proof
International Protection (IP) code: IP66
IK code: IK10
Feature: Weatherproof

Camera

Feature: Camera pan control
Feature: Camera tilt control
Minimum illumination: 0.02 lx
Angle of rotation: 190°
Lens viewing angle, horizontal: 100°
Lens viewing angle, vertical: 52°
Tilt angle range: -45 - 80°
Pan range: -190 - 190°
Camera pixel size: 2.9 µm
Camera shutter speed: 1/37000 - 2 s

Image sensor

Number of sensors: 1
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Sensor type: CMOS

Lens system

Feature: Zoom capability
Number of lenses: 1
Lens diameter: 1 cm
Focal length range: 3.4 - 9.8 mm
Feature: Auto focus
Maximum aperture number: 1.76
Minimum aperture number: 1.7
Detect distance (wide): 48 m
Detect distance (tele): 135 m
Observe distance (wide): 19 m
Observe distance (tele): 54 m
Recognize distance (wide): 9.6 m
Recognize distance (tele): 27 m
Identify distance (wide): 4.8 m
Identify distance (tele): 14 m
Closest focusing distance: 1 m

Night vision

Feature: Night vision
Night vision distance: 40 m
LED type: IR
Infra-red wavelength: 850 nm

Video

Maximum resolution: 1920 x 1080 pixels
Total megapixels: 2 MP
Video formats supported: AV1, AVC, H.264, H.265, HEVC, M-JPEG, MPEG4
Supported graphics resolutions: 1280 x 800 (WXGA), 1440 x 1080, 1920 x 1080 (HD 1080)
Frame rate: 60 fps
Feature: Video streaming
Noise reduction technology: 2D noise reduction, 3D noise reduction
Image quality adjustment: Brightness, Contrast, Saturation, Sharpness
Feature: Flip & mirror
Feature: Text caption overlay
Bit rate control: Variable Bit Rate (VBR)

Audio

Signal-to-Noise Ratio (SNR): 55 dB
Feature: Audio detection

Network

Feature: Ethernet LAN
Ethernet interface type: Fast Ethernet
Networking standards: IEEE 802.1AE, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Streaming method: Multicast

Storage

Feature: Card reader integrated
Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
Flash memory: 8000 MB
RAM capacity: 2000 MB

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1
Feature: Terminal block port

Security

Feature: Video motion detection
Feature: Active tampering alarm
Security algorithms: 256-bit AES-XTS, EAP-TLS, HTTPS, MSCHAPv2, PEAP
Alert notification type: E-mail
Feature: Privacy protection
Feature: Pixel counter
Feature: Human and vehicle targets classification

Management features

Behavior analysis: Line crossing detection

Power

Power source type: PoE
Power consumption (typical): 3.4 W
Power consumption (max): 10 W

Operational conditions

Operating temperature (T-T): -40 - 50 °C
Storage temperature (T-T): -40 - 65 °C
Operating relative humidity (H-H): 10 - 100%
Storage relative humidity (H-H): 5 - 95%

Weight & dimensions

Width: 183 mm
Depth: 156 mm
Height: 149 mm
Weight: 850 g

Sustainability

Compliance certificates: REACH, RoHS, Trade Agreements Act (TAA)

Packaging content

Number of cameras: 1
Feature: Sun shield included
Feature: Manual

Other features

Doesn't contain: CFR, PVC, PVC/BFR
