Axis C1111-E

Axis C1111-E. Recommended usage: Intercom system. Speaker type: 2-way, Number of drivers: 1. Frequency range: 120 - 20000 Hz. Product colour: White

AXIS C1111-E Network Cabinet Speaker

Broadcast clear live or prerecorded voice messages for business efficiency, asset protection, ads, or more with this stylish all-in-one speaker system. It's also suitable for background music.

Smart and easy to integrate

This smart network speaker combines hardware and software in a single cost-effective unit. Built on an open platform, it's made to work with your systems, from your VMS to your VoIP (using SIP) to the analytics you depend on. The built-in microphone supports remote health testing and two-way audio with full duplex and echo cancellation. Plus, AXIS Audio Manager Edge software comes built in, so you can schedule content, set user permissions, and reconfigure zones from anywhere. For coordinating audio across multiple sites, a standard version of our multisite management software, AXIS Audio Manager Center, is also available free of charge.

Good sound for all your audio needs

Enjoy dependable audio, starting the moment you take the speaker out of the box. A preconfigured digital signal processor (DSP) ensures clear voice and background music every time. Live, scheduled, and event-triggered voice messages help you improve business efficiency, keep people safe and informed, and protect your property. The same system also lets you create the right atmosphere with background music. And with flexible audio zoning and content prioritization, you can count on your messages getting to the right place at the right time.

Easy, flexible installation

It doesn't get much easier. A single network cable provides both power and connectivity using Power over Ethernet, so you don't need to fuss with dedicated audio cabling. Its all-in-one design saves space and eliminates the need for external amplifiers or other audio equipment, and the click-in mounting process supports a safe and easy installation. Finally, it's got a visual design worth showing off - in any setting. Sleek and stylish, it's available in white and black, and it's suitable for mounting on walls, ceilings, and poles, both indoors and in semi-protected outdoor installations - for example, under eaves.

Loudspeakers

Speaker type: 2-way
Speaker placement: Wall-mountable
Speaker enclosure: Closed
Number of drivers: 1

Audio

Frequency range: 120 - 20000 Hz
Sound pressure level (max): 93 dB
Audio formats supported: AAC-LC, ADPCM, G.711, G.726, WAV
Beamwidth: 120 - 130°

Performance

Recommended usage: Intercom system
Product colour: White
Housing material: Aluminium
LED indicators: Yes
International Protection (IP) code: IP55

Amplifier

Amplifier: Built-in
Amplifier class: D
Amplifier output power: 7 W

Ports & interfaces

Feature: Microphone in
Feature: Card reader integrated
Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC

Power

Power source type: PoE
Power consumption (typical): 12.95 W

Weight & dimensions

Width: 253 mm
Depth: 129 mm
Height: 164 mm
Weight: 2.2 kg

Packaging content

Feature: Quick start guide

Operational conditions

Operating temperature (T-T): -30 - 50 °C
Storage temperature (T-T): 10 - 100 °C
Operating relative humidity (H-H): -40 - 65%
Storage relative humidity (H-H): 5 - 95%

Sustainability

Doesn't contain: PVC/BFR

Technical details

Compliance certificates: REACH, RoHS
