Ašis P9117-PV

Axis P9117-PV. Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Bullet. Minimum illumination: 0.04 lx, Horizontal field of view (thermal module): 176°, Lens viewing angle, vertical: 176°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"). Focal length range: 1.1 mm

This indoor ligature-resistant (anti-ligature) corner camera delivers 360° panoramic view with no blind spots. Compact and vandal-resistant, it's easy to clean and install.

Great video performance
AXIS P9117-PV is a 6 MP corner camera that delivers full coverage with no blind spots. It includes Axis Lightfinder 2.0 to capture images with more realistic and saturated colors and sharper images of moving objects. And, with Axis Forensic WDR you're sure to capture high-quality images even when there's both dark and light areas in the scene.

Extended possibilities
Built on an Axis system-on-chip, AXIS P9117-PV features Axis edge vault, a hardware-based cybersecurity platform that safeguards the device and protects sensitive information from unauthorized access. With this AI-powered camera, you can run advanced analytics on the edge. For instance, it comes with AXIS Object Analytics preinstalled to detect and classify different objects of interest. With a built-in microphone, it's out-of-the-box-ready for AXIS Audio Analytics. In addition, elevator door state detector will display if the elevator door is open unexpectedly which could indicate a safety or service issue.

Easy to install and maintain
AXIS P9117-PV is easy to install, thanks to innovative screw gaskets that hold the screws in place during mounting. With a vandal-resistant, IK10-rated casing, it's ideal for installation in areas prone to vandalism, such as elevators and stairwells. AXIS TP9801 Cover Steel is also available as an accessory. Furthermore, with an abrasion-and chemical-resistant front cover that's easy to remove, the window can also be cleaned more thoroughly with detergent or graffiti remover.

Performance

Type: IP security camera
Placement supported: Indoor
Connectivity technology: Wired
Feature: Wide Dynamic Range (WDR)

Design

Form factor: Bullet
Mounting type: Ceiling
Product colour: White
Protection features: Vandal proof
International Protection (IP) code: IP66
IK code: IK10

Camera

Feature: Camera tilt control
Minimum illumination: 0.04 lx
Horizontal field of view (thermal module): 176°
Lens viewing angle, vertical: 176°

Image sensor

Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
Sensor type: CMOS

Lens system

Number of lenses: 1
Focal length range: 1.1 mm
Maximum aperture number: 2.2

Night vision

Feature: Night vision

Video

Maximum resolution: 2160 x 2160 pixels
Total megapixels: 6 MP
Video formats supported: H.264, H.265, M-JPEG

Audio

Audio system: 2-way
Feature: Built-in microphone
Feature: Audio detection

Network

Feature: Ethernet LAN
Networking standards: IEEE 802.1x

Security

Feature: Video motion detection
Feature: Active tampering alarm
Feature: HTTPS encryption

Power

Power source type: PoE

Operational conditions

Operating temperature (T-T): -15 - 50 °C
