„Bluechip“ BUSINESSline M1550

bluechip BUSINESSline M1550. Processor family: Intel Core 5, Processor model: 210H. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 5200 MHz. Total storage capacity: 500 GB, Storage media: SSD. On-board graphics card model: Intel® Graphics. Wi-Fi. Operating system installed: Windows 11 Pro, Operating system architecture: 64-bit. Power supply: 120 W. Chassis type: Mini PC. Product type: Mini PC. Product colour: Black

Processor

Processor manufacturer: Intel
Processor family: Intel Core 5
Processor generation: Intel Core (Series 2)
Processor model: 210H
Processor cores: 8
Processor threads: 12
Processor boost frequency: 4.8 GHz
Performance cores: 4
Efficient cores: 4
Efficient-core Max Turbo Frequency: 3.6 GHz
Performance-core base frequency: 2.2 GHz
Efficient-core base frequency: 1.6 GHz
Processor cache: 12 MB
Processor cache type: Smart Cache
Number of processors installed: 1
Processor base power: 45 W
Maximum turbo power: 115 W

Memory

Internal memory: 16 GB
Maximum internal memory: 96 GB
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 2 x 8 GB
Memory slots: 2x SO-DIMM
Memory clock speed: 5200 MHz

Storage

Total storage capacity: 500 GB
Storage media: SSD
Optical drive type: No
Number of storage drives installed: 1
Total SSDs capacity: 500 GB
Number of SSDs installed: 1
SSD capacity: 500 GB
SSD interface: PCI Express 4.0
Feature: NVMe

Graphics

Feature: On-board graphics card
Discrete graphics card model: Not available
On-board GPU manufacturer: Intel
On-board graphics card family: Intel® Graphics
On-board graphics card model: Intel® Graphics

Performance

Feature: Trusted Platform Module (TPM)
Product type: Mini PC
Trusted Platform Module (TPM) version: 2.0
Audio output channels: 7.1 channels

Network

Feature: Ethernet LAN
Ethernet LAN data rates: 2500 Mbit/s
LAN controller: Intel I226-V
Feature: Wi-Fi
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: Wi-Fi 7 (802.11be)
WLAN controller manufacturer: Intel
WLAN controller model: Intel Wi-Fi 7 BE202
Feature: Bluetooth
Bluetooth version: 5.4

Ports & interfaces

USB 2.0 ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Feature: USB Type-C DisplayPort Alternate Mode
Feature: Intel® Thunderbolt 4
Thunderbolt 4 ports quantity: 2
HDMI ports quantity: 2
HDMI version: 2.1
Ethernet LAN (RJ-45) ports: 1

Power

Power supply: 120 W

Design

Chassis type: Mini PC
Feature: VESA mounting
Product colour: Black

Software

Operating system architecture: 64-bit
Operating system installed: Windows 11 Pro

Audio

Audio system: High Definition Audio

Weight & dimensions

Width: 117 mm
Depth: 112 mm
Height: 37 mm

Certificates

Certification: CE
