„Bluechip BUSINESSline“ darbo stotis WS2301

bluechip BUSINESSline Workstation WS2301 Intel® Xeon® w3-2423 Prozessor / bis zu 4.20 GHz, Windows 11 Pro, Intel® W790, 32 GB DDR5, 500 GB NVMe SSD, 2 × RJ45 (10 Gb/s + 2,5 Gb/s), NVIDIA RTX™ 2000 Ada Generation. Processor frequency: 2.1 GHz, Processor family: Intel Xeon W, Processor model: w3-2423. Internal memory: 32 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 4400 MHz. Total storage capacity: 500 GB, Storage media: SSD. Discrete graphics card model: NVIDIA RTX 2000 Ada. Operating system installed: Windows 11 Pro, Operating system architecture: 64-bit. Power supply: 1000 W. Chassis type: Midi Tower. Product type: Workstation. Product colour: Black

Processor

Processor manufacturer: Intel
Processor family: Intel Xeon W
Processor model: w3-2423
Processor cores: 6
Processor threads: 12
Processor boost frequency: 4.2 GHz
Processor frequency: 2.1 GHz
Performance cores: 6
Processor cache: 15 MB
Processor cache type: Smart Cache
Number of processors installed: 1
Processor socket: LGA 4677 (Socket E)
Processor base power: 120 W
Maximum turbo power: 144 W

Memory

Internal memory: 32 GB
Maximum internal memory: 2 TB
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 2 x 16 GB
Memory slots: 8x DIMM
Memory clock speed: 4400 MHz
Memory channels: Dual-channel

Storage

Total storage capacity: 500 GB
Storage media: SSD
Number of storage drives installed: 1
Total SSDs capacity: 500 GB
Number of SSDs installed: 1
SSD capacity: 500 GB
SSD interface: PCI Express 4.0
Feature: NVMe
Feature: Hot-swap drive bays
Feature: RAID support
RAID levels: 0, 1, 5, 10

Graphics

Feature: Discrete graphics card
Discrete GPU manufacturer: NVIDIA
Discrete graphics card model: NVIDIA RTX 2000 Ada
Discrete graphics card memory: 16 GB
Discrete graphics memory type: GDDR6
Number of discrete graphics cards: 1
On-board graphics card model: Not available
Maximum discrete graphics card resolution: 7680 x 4320 pixels
Graphics card Mini DisplayPort ports quantity: 4

Network

Feature: Ethernet LAN
Ethernet LAN data rates: 2500,10000 Mbit/s
LAN controller: Intel I226-V

Ports & interfaces

USB 2.0 ports quantity: 8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Ethernet LAN (RJ-45) ports: 2
Feature: Microphone in
Headphone outputs: 1
Feature: S/PDIF out port
Number of SATA III connectors: 4

Expansion slots

PCI Express x16 (Gen 5.x) slots: 5

Design

Chassis type: Midi Tower
Placement supported: Vertical
Product colour: Black

Performance

Motherboard chipset: Intel W790
Audio chip: Realtek ALC1220A
Audio output channels: 7.1 channels
Product type: Workstation

Software

Operating system architecture: 64-bit
Operating system installed: Windows 11 Pro

Power

Power supply: 1000 W
80 PLUS certification: 80 PLUS Gold

Certificates

Certification: CE

Weight & dimensions

Width: 200 mm
Depth: 490 mm
Height: 435 mm
