ASUS ExpertCenter P500 Mini Tower P500MV-05210H124X

ASUS ExpertCenter P500 Mini Tower P500MV-05210H124X. Processor family: Intel Core 5, Processor model: 210H. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM. Total storage capacity: 512 GB, Storage media: SSD, Card reader integrated, Optical drive type: DVD±RW. On-board graphics card model: Intel® Graphics. Operating system installed: Windows 11 Pro, Operating system architecture: 64-bit. Power supply: 180 W. Chassis type: Mini Tower. Product type: PC. Product colour: Grey

Exceptional Value and Performance for Businesses
ASUS ExpertCenter P500 Mini Tower combines high-performance, business-grade security, and commercial-class services features in a compact and sleek design, providing budget-conscious small and medium business users with a flexible and organized workspace. Designed to withstand tough conditions and meet MIL-STD-810H US military standards1, it features a tool-free and expandable chassis, ensuring prolonged reliability and convenient upgrades for professionals.

Processor

Processor manufacturer: Intel
Processor family: Intel Core 5
Processor generation: Intel Core (Series 2)
Processor model: 210H
Processor cores: 8
Processor threads: 12
Processor boost frequency: 4.8 GHz
Performance cores: 4
Efficient cores: 4
Efficient-core Max Turbo Frequency: 3.6 GHz
Performance-core base frequency: 2.2 GHz
Efficient-core base frequency: 1.6 GHz
Processor cache: 12 MB
Processor cache type: Smart Cache
Processor base power: 45 W
Maximum turbo power: 115 W

Memory

Internal memory: 16 GB
Maximum internal memory: 64 GB
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 1 x 16 GB
Memory slots: 2x SO-DIMM

Storage

Total storage capacity: 512 GB
Storage media: SSD
Optical drive type: DVD±RW
Total SSDs capacity: 512 GB
Number of SSDs installed: 1
SSD capacity: 512 GB
SSD interface: PCI Express 4.0
Feature: NVMe
SSD form factor: M.2
M.2 SSD size: 2280 (22 x 80 mm)
Feature: Card reader integrated
Compatible memory cards: MMC, SD

Graphics

Feature: On-board graphics card
Discrete graphics card model: Not available
On-board GPU manufacturer: Intel
On-board graphics card family: Intel® Graphics
On-board graphics card model: Intel® Graphics

Performance

Market positioning: Business
Feature: Password protection
Password protection type: HDD, User
Feature: Trusted Platform Module (TPM)
Product type: PC
Trusted Platform Module (TPM) version: 2.0
Audio output channels: 7.1 channels

Network

Feature: Ethernet LAN
Ethernet LAN data rates: 10,100,1000 Mbit/s
Feature: Wi-Fi
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-Fi standards: Wi-Fi 6 (802.11ax)
Antenna type: 1x1
Feature: Bluetooth
Bluetooth version: 5.4

Ports & interfaces

USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
DisplayPorts quantity: 1
DisplayPort version: 1.4
HDMI ports quantity: 1
HDMI version: 1.4
Ethernet LAN (RJ-45) ports: 1
Feature: Combo headphone/mic port
Number of rear USB ports: 4
Number of front USB ports: 3
Number of front audio ports: 1
Number of rear audio ports: 3

Expansion slots

Number of 3.5" bays: 1
PCI Express x16 (Gen 4.x) slots: 1

Power

Power supply: 180 W
80 PLUS certification: 80 PLUS Bronze

Design

Chassis type: Mini Tower
Colour name: Grey
Volume: 15 L
Feature: Cable lock slot
Cable lock slot type: Kensington
Product colour: Grey
Introduction year: 2025

Software

Operating system architecture: 64-bit
Operating system installed: Windows 11 Pro

Audio

Audio system: High Definition Audio

Weight & dimensions

Width: 155 mm
Depth: 296 mm
Height: 347 mm
Weight: 6 kg

Packaging data

Package width: 395 mm
Package depth: 246 mm
Package height: 510 mm

Packaging content

Feature: Mouse included
Mouse connectivity: Wired
Feature: Keyboard included

Certificates

Compliance certificates: REACH

Sustainability

Sustainability certificates: ENERGY STAR, EPEAT Silver

Keyboard

Keyboard connectivity: Wired
