ASUS Chromebox CHROMEBOX5-SC002UN

ASUS Chromebox CHROMEBOX5-SC002UN. Processor family: Intel® Celeron®, Processor model: 7305. Internal memory: 4 GB, Internal memory type: DDR4-SDRAM, Memory clock speed: 3200 MHz. Total storage capacity: 128 GB, Storage media: SSD, Card reader integrated. On-board graphics card model: Intel® UHD Graphics. Operating system installed: ChromeOS. Power supply: 65 W. Chassis type: Mini PC. Product type: Mini PC. Weight: 800 g. Product colour: Black

ASUS Chromebox 5 features a 12th Generation Intel® Core™ or Celeron® processor, support for up to four 4K displays, WiFi 6E & 2.5G Ethernet connectivity, 15W wireless charger and Google Play access.

Simple, Speedy and Secure
- Lightning-fast Thunderbolt™ 4
- Support quad 4K displays
- Built-in 15W wireless charger*
- IT management is easier by Chrome Enterprise*
*Wireless charging is an optional function and the maximum charging power depends on the devices.
*Requires Chrome Enterprise Upgrade license.

Ready for Any Task
ASUS Chromebox 5 offers outstanding performance and instantaneous response for incredible productivity. It's powered by up to a 12th Gen Intel® Core™ i7 processor that delivers blistering processing speeds to cater to the most demanding tasks. And with up to 32 GB DDR4 memory, ASUS Chromebox 5 enables easy multitasking without slowdowns.

In addition, Intel Iris® Xe graphics deliver unmatched processing power for stunning, supersmooth visuals. A PCIe® Gen 4 x4 M.2 SSD provides ultrafast data transfers and app launches.

Overall, ASUS Chromebox 5 offers an exceptional user experience that combines superior performance and cutting-edge features for next-level productivity.

Processor

Processor manufacturer: Intel
Processor family: Intel® Celeron®
Processor model: 7305
Processor cores: 5
Processor cache: 8 MB

Memory

Internal memory: 4 GB
Internal memory type: DDR4-SDRAM
Memory slots: 2x SO-DIMM
Memory clock speed: 3200 MHz

Storage

Total storage capacity: 128 GB
Storage media: SSD
Optical drive type: No
Total SSDs capacity: 128 GB
Number of SSDs installed: 1
SSD capacity: 128 GB
SSD interface: PCI Express 3.0
Feature: NVMe
SSD form factor: M.2
Feature: Card reader integrated
Compatible memory cards: MicroSD (TransFlash)

Graphics

Feature: On-board graphics card
Discrete graphics card model: Not available
On-board GPU manufacturer: Intel
On-board graphics card model: Intel® UHD Graphics

Network

Feature: Ethernet LAN
Ethernet LAN data rates: 10,100,1000,2500 Mbit/s
Cabling technology: 10/100/1000Base-T(X)
Feature: Wi-Fi
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi standards: Wi-Fi 6E (802.11ax)
Antenna type: 2x2
Feature: Bluetooth
Bluetooth version: 5.2

Ports & interfaces

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
Feature: Intel® Thunderbolt 4
Thunderbolt 4 ports quantity: 1
HDMI ports quantity: 2
DisplayPorts quantity: 1
DisplayPort version: 1.4
Ethernet LAN (RJ-45) ports: 1
Headphone outputs: 1
Feature: Combo headphone/mic port
Feature: DC-in jack

Design

Chassis type: Mini PC
Colour name: ECO Black
Feature: Cable lock slot
Cable lock slot type: Kensington
Product colour: Black

Performance

Product type: Mini PC

Software

Operating system installed: ChromeOS

Power

Power supply: 65 W

Certificates

Certification: BSMI/CB/CE/FCC/UL/Energy Star/C-Tick/WiFi/RF/VCCI

Weight & dimensions

Width: 166.5 mm
Depth: 165.8 mm
Height: 45.9 mm
Weight: 800 g
Package width: 334 mm
Package depth: 206 mm
Package height: 69 mm
Package weight: 1.8 kg
