TELTONIKA Wi-Fi 5 prieigos taškas be PoE injektoriaus

Equipped with dual-band technology, fast roaming, and an RJ45 port with PoE-in functionality, the Teltonika Networks TAP200 is a Wi-Fi 5 wireless access point designed to enhance Wi-Fi coverage in medium-density spaces where high network performance is essential. The TAP200 features an integrated mounting bracket for quick and easy installation, and a sleek design to seamlessly blend into retail, enterprise, or any other environment.

Wi-Fi 5Wave-2 802.11 b/g/n/ac Dual Band Wi-Fi

RJ45 POE-INSupporting speeds of up to 1000 Mbps and PoE-in functionality

RMS MANAGEMENTFree access to RMS Management for 24 months

WirelessWireless mode: 802.11b/g/n/ac Wave 2 (Wi-Fi 5) with data transmission rates up to 867 Mbps (Dual Band, MU-MIMO)

Wi-Fi security: WPA2-EAP/WPA3-EAP Mixed Mode, WPA3-EAP, WPA2-PSK/WPA3-SAE Mixed Mode, WPA3-SAE, OWE, WPA-PSK/WPA2-PSK Mixed Mode, WPA2-PSK, WPA2-EAP; AES-CCMP, TKIP, Auto Cipher modes, isolate clients

SSID/ESSID: ESSID stealth mode (Hide SSID)

Wi-Fi users: Up to 100 simultaneous connections

Wireless mesh/roaming: Fast roaming (802.11r)

Wireless MAC filter: Whitelist, blacklist

EthernetEthernet: 1 x RJ45 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover

NetworkNetwork protocols: TCP, UDP, IPv4, IPv6, ICMP, HTTP, HTTPS, SSL/TLS, ARP, SSH, DHCP client, SMNP

SecurityAuthentication: SSH key based, HTTPS, CLI, IP Login attempts block

VLAN: Tag-based VLAN separation

Monitoring ManagementWEB UI: HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, event log, system log, kernel log

FOTA: Firmware update from server, automatic notification

SSH: SSH (v1, v2)

JSON-RPC: Management API over HTTP/HTTPS

RMS: Teltonika Remote Management System (RMS)

System CharacteristicsCPU: Mediatek, Dual-Core, 880 MHz, MIPS 1004Kc

RAM: 256 MB, DDR3

FLASH storage: 16 MB, SPI NOT Flash

Firmware / ConfigurationWEB UI: Update FW from file, check FW on server, configuration profiles, configuration backup

FOTA: Update FW

RMS: Update FW/configuration for multiple devices at once

Keep settings: Update FW without losing current configuration

Firmware customisationOperating system: RutOS (OpenWrt based Linux OS)

Supported languages: Busybox shell, Lua, C, C++

Development tools: SDK package with build environment provided

PowerConnector: RJ45 Socket

Input voltage range: 44.0 - 57.0 V

PoE standards: 802.3af PoE Class 1

Power consumption: Idle <4 W / Max: <5.5 W

!!! Power supply not included !!!

Physical InterfacesEthernet: 1 x RJ45 ports, 10/100/1000 Mbps

Status LEDs: 1 x Power LED (can be turned off from web-UI)

Antennas: 2 x Internal for 2.4 GHz Wi-Fi, 2 x Internal for 5 GHz Wi-Fi

Reset: Reboot/User default reset/Factory reset button

Physical SpecificationCasing material: UV stabilized plastic

Dimensions: Ø 158 mm x 30 mm

Weight: 190 g

Mounting options: AP Mounting Bracket (for ceiling mount)

Operating EnvironmentOperating temperature: -40 °C to 75 °C

Operating humidity: 10% to 90% non-condensing

Ingress Protection Rating: IP30

Regulatory Type ApprovalsRegulatory: CE, UKCA, FCC, IC, RCM, CB, EAC, UCRF, WEEE

EMC Emissions ImmunityStandards:

EN 55032:2015+A11:2020

EN 55035:2017+A11:2020

EN 61000-3-3:2013+A1:2019+A2:2021

EN IEC 61000-3-2:2019+A1:2021

EN 301 489-1 V2.2.3

EN 301 489-17 V3.2.4

ESD: EN 61000-4-2:2009

RS: EN IEC 61000-4-3:2020

EFT: EN 61000-4-4:2012

Surge protection: EN 61000-4-5:2014+A1:2017

CS: EN 61000-4-6:2014

DIP: EN IEC 61000-4-11:2020

RFStandards: EN 300 328 V2.2.2; EN 300 893 V2.1.1; EN 300 440 V2.2.1

SafetyStandards:

IEC 62368-1:2018

EN IEC 62368-1:2020+A11:2020

EN IEC 62311:2020

Package contains:- Access Point TAP200

- QSG (Quick Start Guide)

- Wi-Fi Information sticker

- Packaging box
