Teltonika RUT260 mobiliojo ryšio tinklo įrenginys

Teltonika RUT260. Device type: Cellular network router, Product colour: Black, Blue, Housing material: Aluminium, Plastic. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.11r, IEEE 802.3, IEEE 802.3af,.... Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n), WLAN data transfer rates supported: 300 Mbit/s. Data network: 3G, LTE, SIM card type: MiniSIM, Data transfer rate (LTE) (download): 300 Mbit/s. Security algorithms: AES-CCMP, TKIP, WEP, WPA2-Enterprise-PEAP, WPA2-PSK, WPA3-EAP, WPA3-SAE

RUT260 is a Teltonika Networks LTE Cat 6 cellular router with WAN failover. Balancing the key features of the RUT240 and RUT360, this cellular router is powerful, lightweight, and supports a wide variety of industrial protocols, including MQTT, SNMP, Modbus, and more.

Design

Device type: Cellular network router
Product colour: Black, Blue
Housing material: Aluminium, Plastic
Mounting: DIN-rail/Wall mounting
Market positioning: Industrial
Feature: Suitable for indoor use
LED indicators: LAN, Network, Power, Signal strength, WAN

Ethernet LAN features

Feature: Ethernet LAN
Ethernet LAN interface type: Fast Ethernet
Ethernet LAN data rates: 10,100 Mbit/s
Networking standards: IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.11r, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u
Feature: DHCP client
Feature: DHCP server
Feature: Full duplex

Wireless LAN features

Feature: Wi-Fi
Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rates supported: 300 Mbit/s

Mobile network

Data network: 3G, LTE
Number of SIM cards: 1
SIM card type: MiniSIM
Feature: Short Message Service (SMS)
Data transfer rate (LTE) (download): 300 Mbit/s
Data transfer rate (LTE) (upload): 50 Mbit/s

Ports & interfaces

Ethernet LAN (RJ-45) ports: 2

Security

Security algorithms: AES-CCMP, TKIP, WEP, WPA2-Enterprise-PEAP, WPA2-PSK, WPA3-EAP, WPA3-SAE
Feature: Network address translation (NAT)
Feature: Firewall
Feature: IP address filtering
Feature: DMZ support

Performance

Feature: Built-in processor
Processor manufacturer: Mediatek
Processor frequency: 0.58 GHz
RAM capacity: 0.128 GB
Internal storage capacity: 0.016 GB
Operating system installed: RutOS
Feature: Web-based management
Antenna type: External
Antenna connector type: SMA/RP-SMA
Antennas quantity: 3
Feature: Detachable antenna(s)

Power

Power source type: DC

Operational conditions

Operating temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 10 - 90%

Weight & dimensions

Width: 83 mm
Depth: 74 mm
Height: 25 mm
Weight: 130 g
