TELTONIKA 2 kontaktų 130 W maitinimo šaltinis, ES tipo

Compatible with TSW200, TSW202, TSW212 switches.

GENERALInput voltage: 100 - 240 VAC

Input frequency: 50 / 60 Hz

Input current: 2.5 A

Input connector: EU (Type C)

Output voltage: 50 VDC

Output current: 2.6 A

Output connector: 2-pin, with cord end terminals

Weight: 500 g

ADDITIONALInput voltage range: 90 - 264 VAC

Input frequency range: 47 - 63 Hz

Maximum input inrush current: 50 A

Output voltage maximum deviation: 47.5 - 52.5 VDC

Short circuit protection: Yes

HIPOT (dielectric withstand test): Primary to Secondary: 4242 VDC

MTBF: 50000 h

PSU efficiency standard: DoE Level VI

Certification:

Safety: EN 60335-1:2012+A11:2014+A13:2017, EN 60335-2-29:2004+A2:2010+A11:2018, EN 62233:2008

EMC: EN 55014-1:2017, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55014-2:2015 (IEC 61000-4-2:2008, IEC 61000-4-4:2012, IEC 61000-4-5:2014, IEC 61000-4-6:2013, IEC 61000-4-11:2004+A1:2017)
